Ubiquiti EdgeRouter 12 (ER-12) Advanced Network Router 12 Port Gigabit, 3.4MPPS

Product Specification

Overview

Ubiquiti EdgeRouter 12 (ER-12) Advanced Network Router 12 Port Gigabit, CPU 4 Core 1GHz, Ram 1GB, 3.4Million PPS, 2 SFP Port, POE Passthrough, VPN IPSecs, OpenVPN, PPTP, L2TP

Dimensions

268.1 x 136.5 x 31.1 mm (10.55 x 5.37 x 1.22")

Weight

700 g (1.54 lb)

Max. Power Consumption

20W (Excludes PoE Output)

Power

External AC Power Adapter, 24W (24V, 1A) (Included)
24V Passive PoE

Power Input

AC: 110 - 240VAC, 50/60 Hz
24V Passive PoE: 20 - 30V

Button

Reset

LEDs

Data Ports: Speed/Link/Activity, PoE (Ports 0 and 9 only)
SFP Data Port: Link/Activity

Networking Interfaces

Management: (1) RJ45 Serial Port

Networking

(10) Ethernet Ports (Default Port 0)
(10) 10/100/1000 RJ45 Ports
(2) 1 Gbps SFP Ports

Layer 3 Forwarding Performance

Packet Size: 64 Bytes: 3,400,000 pps
Packet Size: 512 Bytes or Larger: 12 Gbps (Line Rate)

Processor

4-Core 1 GHz, MIPS64

System Memory

1 GB DDR3 RAM

On-Board Flash Storage

4 GB eMMC, 8 MB SPI NOR

Mounting

Rack*

Operating Temperature

-10 to 50? C (14 to 122? F)

Operating Humidity

10 - 90% Noncondensing

Certifications

CE, FCC, IC

PoE Interfaces

PoE In: (1) 24V Passive PoE Port, 2-pair (4, 5+; 7, 8-)
PoE Out: (1) 24V Passive PoE Port, 2-pair (4, 5+; 7, 8-)

Passive PoE Max. Wattage Per Port

20W (24V, 0.83A)

Voltage Range Passive PoE

24V: 21 - 27V

รับประกัน

1 ปี
