US-48 Ubiquiti Unifi Switch L2-Managed Gigabit Switch 48 Port 4 SFP

Product Specification

Overview

Ubiquiti Unifi Switch US-48 L2-Managed Gigabit Switch 48 Port,  4 Port SFP รองรับ VLAN ควบคุมการทำงานผ่าน Unifi Software Controller

Dimensions

443 x 43 x 221 mm (17.44 x 1.69 x 8.70")

Weight

3.65 kg (8.06 lb)

Networking Interfaces

(48) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1/10 Gbps SFP+ Ethernet Ports
(2) 1 Gbps SFP Ethernet Ports

Management Interface

(1) RJ45 Serial Port Out-of-Band, Ethernet In-Band

Total Non-Blocking Throughput

70 Gbps

Switching Capacity

140 Gbps

Forwarding Rate

104.16 Mpps

Power Method

100-240VAC/50-60 Hz, Universal Input

Power Supply

AC/DC, Internal, 56W DC

Max. Power Consumption

56W

LEDs per Port

Speed/Link/Activity

Sound Level

37 dBa

ESD/EMP Protection

Air:  24 kV, Contact:  24 kV

Rack Mount

Yes, 1U High

Shock and Vibration

ETSI300-019-1.4 Standard

Operating Temperature

-5 to 40? C (23 to 104? F)

Operating Humidity

5 to 95% Noncondensing

Operating Humidity

5 to 95% Noncondensing

ประกัน

2 ปี
