Ubiquiti Unifi Switch USW-48-POE Product Specification
|
|
Overview
|
Ubiquiti Unifi Switch Gen 2 USW-48-POE L2 Managed Gigabit POE Switch 48 Port ความเร็ว Gigabit, 4 Port SFP 1Gbps, จ่ายไฟ POE 802.3af/at 32 Port 195W ควบคุมผ่าน Unifi Software
รองรับ VLAN 802.1q, Operation mode (switching, mirroring, or aggregate) per port, 802.1X control and RADIUS VLAN, Spanning tree
|
| Total Non-Blocking Throughput |
52 Gbps
|
| Switching Capacity |
104 Gbps
|
|
Dimensions
|
442.4 x 399.6 x 43.7 mm
(17.42 x 15.73 x 1.72")
|
|
Weight
With Rackmount Brackets
|
4.52 kg (9.97 lb)
4.61 kg (10.16 lb)
|
|
Interfaces Networking Management
|
(48) 10/100/1000 RJ45 Ports
(4) 1G SFP Ethernet Ports
Ethernet In-Band
|
|
Power Method
Universal Input
USP RPS DC Input
|
100-240VAC/50-60 Hz
52VDC, 11.54A; 11.5VDC, 5.22A
|
|
Power Supply
|
AC/DC, Internal, 240W
|
|
Supported Voltage Range
|
100 to 240VAC
|
|
Max. Power Consumption (Excluding PoE Output)
|
45W
|
|
LEDs
System
RJ45 Data Ports
SFP Data Ports
|
Status
PoE; Speed/Link/Activity
Link/Activity
|
|
ESD/EMP Protection
|
Air: ± 16 kV, Contact: ± 12 kV
|
|
Shock and Vibration
|
ETSI300-019-1.4 Standard
|
|
Operating Temperature
|
-5 to 40° C (23 to 104° F)
|
|
Operating Humidity
|
10 to 90% Noncondensing
|
|
Certifications
|
CE, FCC, IC
|
|
PoE Interfaces Ports 1-32
|
POE+ IEEE 802.3af/at, (pins 1, 2+; 3, 6-)
|
|
Max. PoE Wattage per Port by PSE
|
802.3at: 32W
|
|
Voltage Range 802.3af Mode
|
44-57V
|
|
Voltage Range 802.3at Mode
|
50-57V
|
|
25% PoE Load, 25° C Room Temperature
|
0.9 dBr
|
|
50% PoE Load, 25° C Room Temperature
|
7.3 dBr
|
|
100% PoE Load, 40° C
|
22.5 dBr
|
|
ประกัน
|
1 ปี
|
