Product Specification
|
|
Overview
|
UCG-Ultra Cloud Gateway Ubiquiti Unifi Ultra Compact Cloud Gateway รองรับการ Managed UniFi 30+ device
รองรับจำนวน Client ได้ 300+
1 Gbps IPS routing, และ Port WAN ความเร็ว Multi-Gig รองรับ Loadbalance/ Failover
|
Mechanical
|
|
Dimensions
|
141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
|
|
Weight
|
520 g (1.1 lb)
|
|
Enclosure materials
|
Polycarbonate
|
Hardware
|
|
Processor
|
Quad-core ARM® Cortex®-A53 at 1.5 GHz
|
|
Memory information
|
3 GB DDR3L
|
|
On-board storage
|
16 GB eMMC
|
|
Management interface
|
EthernetBluetooth
|
|
Networking interface
|
(1) 1/2.5GbE RJ45 WAN port
(1) GbE RJ45 LAN port
|
|
LCM display
|
0.96" status display
|
|
Power method
|
USB type C (5V/3A)
|
|
Supported voltage range
|
100-240V
|
|
Max. power consumption
|
6.2W
|
|
Operating temperature
|
-10 to 40° C (14 to 104° F)
|
|
Operating humidity
|
5 to 95% noncondensing
|
|
Certifications
|
CE, FCC, IC
|
Gateway Features
|
|
Performance
|
Redundant WAN with failover and load balancingWiFi QoS with UniFi APsApplication, domain, and country-based QoSApplication and device type identificationAdditional internet failover with LTE BackupInternet quality and outage reporting
|
|
Next-generation security
|
Application-aware firewall rulesSignature-based IPS/IDS threat detectionContent, country, domain, and ad filteringVLAN/subnet-based traffic segmentationFull stateful firewall
|
|
Advanced networking
|
License-free SD-WANWireGuard, L2TP and OpenVPN serverOpenVPN clientOpenVPN and IPsec site-to-site VPNOne-click Teleport and Identity VPNPolicy-based WAN and VPN routingDHCP relayCustomizable DHCP serverIGMP proxyIPv6 ISP support
|
Application Requirements
|
|
UniFi Network
|
UniFi iOS™: Version 10.12.0 and laterUniFi Android™: Version 10.11.2 and later
|
|
รับประกัน
|
1 ปี
|
