Ubiquiti Unifi Switch USW-Ultra-210W
|
|
Product Specification
|
|
|
Overview
|
Ubiquiti Unifi Switch USW-Ultra-210W L2-Managed Gigabit POE Switch ขนาด 8 Port ความเร็ว Gigabit
จ่ายไฟ POE มาตรฐาน 802.3af/at 7 Port 202W
รองรับ input PoE++[optional ]
|
|
Dimensions
|
203 x 76 x 33 mm (8 x 3 x 1.3")
|
|
WeightWith Rackmount Brackets
|
Device: 320 g (11.3 oz)Wall mount: 45 g (1.6 oz)210W adapter: 770 g (1.7 lb)
|
|
Enclosure material
|
Polycarbonate
|
|
InterfacesNetworkingManagement
|
(8) GbE RJ45 ports Ethernet In-Band
|
|
PoE interface
|
(7) PoE/PoE+ (Pins 1, 2+; 3, 6-)(1) PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
|
|
Button
|
Factory reset
|
|
Power Method
|
(1) 54V, 3.9A power adapter (Included)PoE++ (Pins 1, 2+; 3, 6- and 4, 5+; 7, 8-)
|
|
Power Supply
|
54V, external, 3.9A/210W
|
|
Supported Voltage Range
|
44-57V DC
|
|
Max. Power Consumption (Excluding PoE Output)
|
9W with PoE input (Excluding PoE output)8W with AC adapter input (Excluding PoE output)
|
|
Total available PoE
|
PoE++ input: 42WPoE+ input: 16W60W PoE adapter input: 42W60W AC adapter input: 52W210W AC adapter input: 202W**At 45° C (113° F) operating temperature. Reduced to 161W (230V) or 121W (115V) at 60° C (140° F)
|
|
Layer 2 features
|
Port isolationStorm controlPort mirroringMulticast / broadcast rate limitingFlow controlJumbo framesEgress rate limit
|
|
Layer 3 features
|
-
|
|
Total non-blocking throughput
|
8 Gbps
|
|
Switching capacity
|
16 Gbps
|
|
Operating Temperature
|
PoE++ input: -30 to 60° C (-22 to 140° F)
60W AC adapter input: -20 to 45° C (-4 to 113° F)
210W AC adapter input: -20 to 60° C (-4 to 140° F)
|
|
Operating Humidity
|
10 to 90% Noncondensing
|
|
Certifications
|
CE, FCC, IC
|
|
Max. PoE Wattage per Port by PSE802.3at
|
30W
|
|
UniFi Network
|
Version 8.0.7 and later
|
|
ประกัน
|
3 ปี
|
