| Buffer Size (Mbit) |
16 |
| Switching Capacity (Gbps) |
240 |
| Forwarding Rate (64 bytes)(Mpps) |
178.56 |
| MAC Address Table |
32K |
| Max. Jumbo Frame (KB) |
12 |
| L3 Routing Table |
Support |
Ports
|
| SFP+ (10G) |
12 |
| Console (RJ-45) |
1 |
Standard Compliance
|
| Ethernet Standards |
802.3ab 1000Base-T
802.3ae 10GBase-X
802.3x Flow Control
802.3 Auto-Negotiation
802.1q Tag-based VLAN
802.1p Class of Service
802.1d STP
802.1w RSTP
802.1s MSTP
802.3ad LACP
802.1ad QinQ
802.1x Port Access Control
802.1AB LLDP
802.3az EEE
|
Spanning Tree
|
| STP |
Support |
| RSTP |
Support |
| MSTP |
Support |
Link Aggregation
|
| Max. Number of Group |
8 |
| Max. Number of Member in Each Group |
8 |
| Type |
LACP, Static |
| Traffic Load Balancing |
Support |
VLAN
|
| Max. Number of VLAN |
256 |
| VLAN Type |
802.1q Tag-based VLAN
MAC-based VLAN
Protocol-based VLAN
Management VLAN
Voice VLAN
Surveillance VLAN
|
| GVRP |
Support |
| QinQ (Basic) |
Support |
Layer3 Features
|
| Static Route |
Support |
| VLAN Route |
Support |
| DHCP Server |
Support |
Multicast
|
| IGMP Snooping |
v2, v3(BISS) |
| IGMP Querier |
Support |
| MLD Snooping |
v1, v2 |
| Max. Number of Multicast Group |
256 |
| Multicast Group Filtering / Throttling |
Support |
| MVR (Multicast VLAN Registration) |
Support |
ONVIF Surveillance
|
| Discovery |
Support |
| Surveillance Topology |
Support |
| Real-Time Video Streaming |
Support |
| ONVIF Device Maintenance |
Device Info
Network Settings
Time Settings
Reboot
Reset to Factory Default
|
QoS
|
| Number of QoS Queues |
8 |
| Queue Schedule |
SPQ, WRR |
| CoS (Class of Service) |
CoS
DSCP
CoS-DSCP
IP Precedence
|
| Rate Limiting |
Support |
Security
|
| Authentication Server |
RADIUS, TACACS+ |
| 802.1X/MAC Authentication |
Support |
| IP Source Guard |
Support |
| Traffic Control |
DoS Defense, Storm Control |
| Dynamic ARP Inspection (DAI) |
Support |
| DHCP Snooping |
Support |
| IP Conflict Prevention |
Support |
| Loop Protection |
Support |
OpenFlow
*The OpenFlow functionality is project-based and must be activated by DrayTek HQ. Please contact your Sales for further inquiries.
|
| Version |
1.3 |
| Table Size |
1920 |
Management
|
| Local Service |
HTTP
HTTPSTelnet
SSH v2
|
| Config Backup/Restore |
Support |
| Dual Image |
Support |
| 2-Level Administration Privilege |
Support |
| Access Control |
Access List |
| OpenVPN Client |
Support |
| sFlow |
Support |
| SNMP |
v1, v2c, v3 |
| RMON Group |
1, 2, 3, 9 |
| SNTP (Simple Network Time Protocol) |
Support |
| LLDP |
Support |
| LLDP-MED |
Support |
| Mail Alert |
Port Status
Port Speed
System Restart
IP Conflict
Hardware Monitor
Device Check
ONVIF IP Cam Snapshot
|
| VigorRouter Management (SWM) |
Support |
| VigorConnect Management (Since f/w) |
V3.7.0 |
| VigorACS Management (Since f/w) |
V3.7.0 |
Physical
|
| Rack Mountable |
1U |
| Power Input |
AC 100-240V @ 2A |
| Backup Power Input |
DC +12V |
| Max. Power Consumption (watts) |
28.9 |
| Dimension (mm) |
441 x 197 x 44 |
| Operating Temperature |
0 to 50°C |
| Storage Temperature |
-20 to 70°C |
| Operating Humidity (non-condensing) |
10 to 90% |
| Storage Humidity (non-condensing) |
5 to 90% |
|
