EnGenius ECS5512 Cloud Managed 8-Port 10-Gigabit, 4SFP+ 10Gbps, ควบคุมการทำงานด้วย EnGenius Cloud
สอบถามข้อมูลสินค้าเพิ่มเติม
LINE ID: @sysnet โทร: 02 102 4284
Cloud Enabled Network Switches Datasheet
EnGenius Cloud Management Datasheet
CloudSwitch Aggregate 8XG _ECS5512 Datasheet
EnGenius Cloud User Manual
การเลือกใช้ POE (Power Over Ethernet) แบบ Passive และ แบบมาตรฐาน 802.3af/at
ECS5512 Product Specification | |
Overview | EnGenius ECS5512 Cloud Managed 8-Port 10-Gigabit, 4SFP+ 10Gbps, ควบคุมการทำงานด้วย EnGenius Cloud |
Technical Specifications | |
| Port Standards | 802.3 10Base-T Ethernet 802.3u 100Base-TX Ethernet 802.3ab 1000Base-T Ethernet 802.3x Full-Duplex Flow Control |
| Network Ports | 8 x 100/1000/2500/5000/10000 Mbps Ports 4 x SFP+ Ports |
| Switching Capacity | 240 Gbps |
| SDRAM | 512 MB |
| Flash Memory | 128 MB |
| PoE Capable Ports | - |
| Total PoE Budget | - |
| Power Source | 100 ~ 240VAC, 50-60Hz |
Physical Interface | |
| System Indicators | Power LED Fault LED PoE Max LED LAN Mode LED PoE Mode LED |
| Port Indicators | Link/Activity/Speed (per Ethernet port) Link/Activity/Speed (per SFP slot) |
L2 Features | |
| Network Management | EnGenius Cloud Local Web GUI |
| MAC Address Table | 32K |
| Jumbo frame size | 10K |
| Multicast Group | Max 256 groups |
| MLD Snooping | MLD Snooping: v1 |
| QoS | Cos/802.1p DSCP CoS/802.1p-DSCP |
| Scheduling Mechanism | Strict / WRR/ Strict + WRR |
| Bandwidth Control | Port-based bandwidth control (Ingress/Egress) |
| Port Security | Max. 256 Entries |
| Access Control List (ACL) | MAC Based ACL IPv4/IPv6 Based ACL ACL Binding |
| Web Graphical User Interface (GUI) | HTTP IPv4 / IPv6 HTTPS IPv4 / IPv6 |
| SNMP | SNMP v1/v2c/v3 Support |
| RMON | RMON 1,2,3,9 |
| System Time | Time Setting/Daylight saving |
| Common L2 Features | 802.1D Spanning Tree 802.1w Rapid Spanning Tree 802.1S Rapid Spanning Tree Loopback Detection Multicast Filitering IGMP Snooping 802.1Q VLAN tagging 802.3x flow control 802.3ad Link Aggregation IPv4 DHCP Relay IPv4 DHCP Snooping IPv4 DHCP Snooping Source MAC Address Check-up ARP Packet Validation (additional validation checks) Voice VLAN Port-based VLAN CoS Mapping 802. 1X Radius Authentication Protocol IPv4 Settings/ IPv6 Settings IEEE 802. 3az Energy Efficeient Ethernet (EEE) Command Line Interface (CLI) SSH Server Telnet Server TFTP Client Configuration Upgrade/ Backup Simple Network Time Protocol (SNTP) SYSLOG |
L3 Features | |
| Multiple IP Interface | 20 IPv6 address |
| ARP Table | Max. 192 ARP entries |
| IPv4 Static Route | Max. 63 entries |
| IPv6 Static Route | Max. 21 entries |
Environmental & Physical | |
| Temperature Range | Operating: 32°F to 122°F (0°C to 50°C) |
| Humidity (Non-Condensing) | 5% – 95% |
| Dimensions & Weight | Weight: 3.1 kg |
รับประกัน | |
| ประกัน | 5 ปี |
