Product Specification |
Standards | IEEE 802.11b/g/n on 2.4 GHz
IEEE 802.11a/n/ac on 5 GHz
IEEE 802.3at
IEEE 802.1r
IEEE 802.1k
IEEE 802.11x |
Memory Capacity | Memory: 256 MB
Flash Memory 32 MB |
Antenna | เสาอากาศ 4 ต้น กระจายสัญญาณรอบทิศทาง Gain ขยาย 5 dBi Dual-Concurrent Omni-Directional Antenna
หัวต่อแบบ SMA-Type ถอดเปลี่ยนเสาได้ |
Physical Interface | 2 x 10/100/1000 Gigabit Ethernet Ports
- LAN1: Supports 802.3at PoE Input
- LAN2: Data Pass Through
1 x Reset Button |
LED Indicators | 1 x Power
WLAN (Wireless Connection)
2.4 GHz
5 GHz
2 x LAN |
Power Source | PoE Injector (EPA2410GP)
INPUT: 100-240VAC, 0.7A, 50-60Hz
OUTPUT: 24V, 1A |
Mounting | Wall Mount
Pole Mount |
Surge Protection | 2KV |
ESD Protection | Contact: 4KV
Air: 8 KV |
Ingress Protection Marking | IP55-Rated Waterproof/Dustproof Enclosure |
Wireless & Radio Specifications |
Operating Frequency | Dual-Radio Concurrent 2.4GHz & 5GHz |
Operation Modes | Access Point Mode (AP mode)
Client Bridge Mode (CB Mode)
WDS: WDS AP, WDS Bridge, WDS Station |
Frequency Radio | 2.4GHz: 2400 MHz ~ 2835 MHz
5GHz: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz, 5725MHz ~ 5850MHz |
Transmit Power | Up to 23 dBi on 5 GHz
Max transmit power is limited by regulatory power |
Radio Chains/Spatial Streams | 11AC Wave2 2x2:2 |
Tx Beamforming (TxBF) | Yes |
SU-MIMO | Two (2) Spatial Stream SU-MIMO up to 1267 Mbps to a single client |
MU-MIMO | Two (2) Spatial Stream MU-MIMO up to 867 Mbps to two (2) wireless devices simultaneously |
Supported Data Rates (Mbps) | 2.4 GHz: Max 400
5 GHz: Max 867
802.11b: 1, 2, 5.5, 11
802.11g: 6, 9, 12, 18, 24, 36, 48, 54
802.11n: 6.5 to 400 (MCS0 to MCS15)
802.11ac: 6.5 to 867 (MCS0 to MCS9, NSS=1~2) |
Supported Radio Technology | 802.11b: Direct-Sequence Spread-Spectrum (DSSS)
802.11a/g/n/ac: Orthogonal frequency-division Multiplexing (OFDM) |
Channelization | 802.11ac supports very high throughput (VHT)—VHT 20/40/80 MHz
802.11n supports high throughput (HT)—HT 20/40 MHz
802.11n supports very high throughput (VHT) under the 2.4 GHz radio—VHT (256-QAM)
802.11n/ac packet aggregation: AMPDU, ASPDU |
Supported Modulation | 802.11b: BPSK, QPSK, CCK
802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM |
Management |
Multiple BSSID | Supports up to 16 SSIDs, 8 SSIDs per radio |
VLAN Tagging | Supports 802.1q SSID-to-VLAN tagging
Cross-band VLAN Pass Through
Management VLAN |
Spanning Tree | Yes |
QoS | Compliant with IEEE 802.11e Standard
WMM |
SNMP | v1, v2c, v3 |
MIB | I/II, Private MIB |
Wireless Features |
AP Radio Settings | Band Steering
Traffic Shaping
Fast Roaming (802.11k & 802.11r)
RSSI Threshold
AP Client Limiting
VLANs for AP - Multiple SSIDs
Secured Guest Network
Email Alert
Wi-Fi Scheduler
Traffic Shaping
Client Traffic Status
PMK Caching
Distance Control (ACK Timeout)
Power Save Mode (U-APSD Support) |
Management Features |
Deployment Options | Standalone (Individually Managed) |
Configuration | Web Interface (HTTP)
CLI (Telnet) |
Control Features | Auto Reboot
Firmware Upgrade |
Security | WPA/WPA2 Enterprise
Hide SSID in beacons
MAC Address Filtering
RADIUS Accounting (802.1x)
Https Support
SSH Support
Client Isolation
L2 Isolation |
Environmental & Physical |
Temperature Range | Operating: -4?F to 140?F, -20?C to 60?C
Storage: -22?F to 176?F, -30?C to 80 ?C |
Humidity (Non-condensing) | Operating: 90% or less
Storage: 90% or less |
Device Dimensions & Weights |
ENS620EXT Device | Weight: 1.11 lbs. (507 g)
Width: 7.54” (191.6 mm)
Length: 4.49” (114.3 mm)
Height” 1.88” (47.7 mm) |
Package Contents | - ENS620EXT 11ac Wave 2 Outdoor AP
- PoE Injector (EPA2410GP)
- Pole Mount Ring
- Mounting Screw Set
- RJ-45 Ethernet Cable
- Quick Installation Guide
- 2 - 2.4GHz 5dBi SMA Antennas
- 2 - 5GHz 5dBi SMA Antennas |
Certifications | FCC
IC |
Warranty | 3 ปี
|
