Product Specification |
Interface Port | 48 Port Gigabit 10/100/1000Mbps
4 Port SFP Slot 10/100/1000Mbps |
| SDRAM: 256MB
Flash Memory: 32MB |
รองรับ EWS Access Point | 50 Device |
Standard Switching Capacity | 104 Gbps |
Layer 2 Switching |
802.3ad Link Aggregation | Maximum of 8 groups/8 ports per group |
Port Mirroring | One-to-One
Many-to-One |
Spanning Tree Protocol | 802.1D Spanning Tree Protocol (STP)
802.1w Rapid Spanning Tree Protocol (RSTP)
802.1s Multiple Spanning Tree Protocol (MSTP) |
MAC Address Table | 8K entries |
Static MAC Address | 256 entries |
| 802.1ab Link Layer Discovery Protocol |
IGMP Snooping | IGMP v1/v2/v3 Snooping
Supports 256 IGMP Groups
IGMP per VLAN
IGMP Snooping Querier
IGMP Snooping Fast Leave |
MLD Snooping | MLD Snooping v1/v2
Supports 256 MLD groups
MLD per VLAN |
Jumbo Frame | up to 9216 bytes |
| 802.3x Flow Control |
| 802.3az Energy Efficient Ethernet |
VLAN | 802.1Q VLAN Tag supported
Voice VLAN |
VLAN Group | Max 4094 Static VLAN Groups |
QoS |
802.1p Quality of Service | - 8 queues per port |
Queue Handling | Strict
Weighted Round Robin (WRR) |
QoS based on | 802.1p Priority
DSCP |
Bandwidth Control | Port-based (Ingress/Egress, 64 Mbps~1000Mbps) |
| Broadcast/Unknown Multicast/ Unknown Unicast Storm Control |
Access Control List (ACL) |
Layer 2/3 | Supports Max. 50 Entries (ACL)
Supports Max. 256 Entries (ACE) |
ACL based on | MAC Address
VLAN ID
802.1p Priority
Ethertype
IP Address
Protocol Type
DSCP |
Security |
802.1X | Guest VLAN
Port-based Access Control |
Port Security | up to 256 MAC Addresses per Port |
| Supports RADIUS Authentication
Port Isolation
DoS Attack Prevention
BPDU Attack Prevention |
Monitoring | Port Statistics
System Log
RMON |
Management | Web Graphical User Interface (GUI)
Command Line Interface (CLI)
BootP/DHCP Client/DHCPv6 Client
SSH Server
Telnet Server
TFTP Client
HTTPS
SNMP Supports v1/v2c/v3
SNTP
Configuration Restore/Backup
Dual Images |
Diagnostic | Cable Diagnostic
Ping Test
Trace Route |
MIB/RFC Standards | RFC1213
RFC1493
RFC1757
RFC2674
RF2863 |
Wireless Management Features | Manage up to 50 Neutron Access Points
Access Point Auto Discovery and Provisioning
Access Point Auto IP Assignment
Access Point Cluster Management
Remote Access Point Rebooting
Access Point Device Name Editing
Access Point Radio Settings
Band Steering
Traffic Shaping
Fast Handover
Fast Roaming
Access Point Client Limiting
Client Fingerprinting
Wireless Security (WEP, WPA/WPA2 Enterprise, WPA/WPA2 PSK)
AP VLAN Management
VLANs for Access Point- Multiple SSIDs
Secured Guest Network
Captive Portal
Access Point Status Monitoring
Rogue AP Detection
Wireless Client Monitoring
Background Scanning
Email Alert
Wireless Traffic & Usage Statistics
Real-time Throughput Monitoring
Visual Topology View
Floor Plan View
Map View
Wireless Coverage Display
Secure Control Messaging (SSL Certificate)
Local MAC Address Database
Remote MAC Address Database (RADIUS)
Unified Configuration Import / Export
Bulk Firmware Upgrade Capability
One-Click Update
Intelligent Diagnostics
Kick/Ban Clients |
Environmental Specifications |
Temperature Range | |
Operating Temperature | 0 to 40?C (EWS1200D-10T)
0 to 50?C (EWS1200-28T/EWS1200-52T) |
Storage Temperature | 20?C to 70?C |
Humidity | 5% ~ 95% |
Package Content |
EWS1200D-10T | EnGenius Switch
Power Adapter
Wall-mount Kit
Quick Installation Guide |
EWS1200-28T & EWS1200-52T | EnGenius Switch
Power Cord
Rack-mount Kit
Quick Installation Guide |
Physical Specifications |
EWS1200D-10T | Weight: 0.61kg
Dimensions (W x D x H): 240 x 105 x 27 mm |
EWS1200-28T | Weight: 3.01kg
Dimensions (W x D x H): 440 x 260 x 44 mm |
EWS1200-52T | Weight: 3.68kg
Dimensions (W x D x H): 440 x 260 x 44 mm |
ประกัน | 3 ปี |
|
