H3C S1850V2-28X-HPWR L2 Managed POE Switch 24 Port Gigabit, 4 SFP+, POE 370W

Overview

H3C S1850V2-28X-HPWR  L2 Managed POE Switch 24 Port Gigabit, 4 Port SFP+ 10 Gigabit รองรับ Static routing, VLAN 802.1q, LACP, 802.1X, IGMP Snooping, SNMP, Port security, ACL จ่ายไฟ POE สูงสุด 370W

Feature

S1850V2-28X-HPWR

Switching capacity

128Gbps

Forwarding capacity

95.232Mpps

CPU

1 Core, 800MHz

Flash/SDRAM

256MB/512MB

Dimensions (W × D × H)

440×260×43.6mm

Weight

≤ 6 kg

Management port

1 console port

Networking interface

24 10/100/1000Base-T electrical ports
4 1G/10G Base-X SFP Plus optical port

Port Surge

6KV

Input voltage

AC: The rated voltage range is 100V to 240V, 50/60Hz.

Total power consumption

MIN: AC: 19W MAX: AC: 448W (PoE 370W)

Fan number

3

MTBF(Year)

52.81

MTTR(Hour)

1

Operating temperature

-5℃ ~ 50℃(normal operating temperature) -5℃ ~ 45℃(When using transceiver modules with maximum transmission distance < 80km) -5℃ ~ 40℃(When using transceiver modules with maximum transmission distance ≥ 80km)

Storage temperature

-40℃ ~ 70℃

Relative humidity (non-condensing)

5% RH to 95% RH, non-condensing

Port aggregation

GE/10GE port aggregation
Dynamic aggregation
Static aggregation

Broadcast/Multicast/Unicast storm suppression

Storm suppression based on port bandwidth percentage
Storm suppression based on PPS
Storm suppression based on BPS
Broadcast traffic/Multicast traffic/Unknown unicast traffic suppression

Ethernet features

802.3x traffic control and half-duplex backpressure
Green Ethernet (EEE)
Automatic port energy-saving

MAC address table

Static MAC address
Blackhole MAC address
Setting the maximum number of port MAC addresses to be learned

VLAN

Port-based VLAN
MAC-based VLAN
VLAN mapping
MVRP
Voice VLAN*

DHCP

DHCP Client
DHCP Snooping
DHCP Snooping option82
DHCP Relay
DHCP auto-config

VLAN interface

Both IPv4 and IPv6 supported

ARP

ARP Detection
ARP speed limit

IP routing

Static routing

Multicast

IGMP Snooping V2/V3
PIM Snooping
MLD Snooping
Multicast VLAN

Layer 2 ring network protocol

STP/RSTP/MSTP/PVST/PVST+
BPDU protection/root protection/loopback protection/protection against TC-BPDU attack

ACL

Packet filtering at Layer 2 through layer 4 Traffic classification based on source MAC addresses, destination MAC addresses, source IPv4/IPv6 addresses,
Time range-based ACL
VLAN-based ACL
Bidirectional ACL

QoS

Port rate limit (receiving and transmitting)
Packet redirection
Committed access rate (CAR)
Eight output queues on each port
Flexible queue scheduling algorithms based on ports and queues, including SP, WRR and SP+WRR
802.1p DSCP remarking

Traffic Statistic

Sflow

Forwarding

Wire-speed/Line-rate architecture

Mirroring

Port mirroring
Traffic mirroring
RSPAN

Security

Hierarchical user management and password protection
AAA authentication support
RADIUS authentication
HWTACACS
SSH2.0
Port isolation
802.1X authentication, centralized MAC authentication
Port security
IP/Port/MAC binding
IP Source Guard
HTTPs

Management and maintenance

Loading and upgrading through XModem/FTP/TFTP
Zero Touch Provisioning
Configuration through CLI, Telnet, and console port
SNMPv1/v2c/v3 and Web-based NMS
Restful
Remote monitoring (RMON ) alarm, event, and history recording
IMC NMS
System log, alarming based on severities, and output of debugging information
NTP
Ping, Tracert
NQA
Virtual cable test (VCT)
Device link detection protocol (DLDP)
Loopback-detection

MAC address entries

16K

Static Mac address

1K

VLAN table

4094

VLAN interface

32

IPv4 routing entries

32

IPv4 ARP entries

128

IPv4 ACL entries

512

IPv4 multicast L2 entries

1000

IPv6 unicast routing entries

16

QOS forward queues

8

IPv6 ACL entries

256

IPv6 ND entries

64

Jumbo frame length

10000

MAX num in one link group

8

Link group num

24

Total PoE power capacity

370W

PoE Ports Quantity

15.4W (802.3af): 24 Port
30W (802.3at): 12 Port

รับประกัน

3 ปี
