    AP160 Huawei eKit Wall plate Access Point WIFI6 1.775Gbps

    Huawei

    Huawei eKit AP160 Wall plate Wireless Access Point 802.11ax 1.775Gbps, Dual-radio 2.4/5GHz, Smart antenna, Managed ผ่าน Cloud/Standalone

    ฿2,250.00
    ยังไม่ได้รวมภาษี
    จำนวน
    50 รายการ


    สอบถามข้อมูลสินค้าเพิ่มเติม

    LINE ID: @sysnet  โทร: 02 102 4284

    Click ต้องการใบเสนอราคา

    close

    แบบฟอร์มขอใบเสนอราคา



    Rating:
    (0)
    รายละเอียด

    Huawei eKitEngine AP160 Wall-Plate Access Point Datasheet



    Huawei eKit AP160

    Wall plate 86x86 AP | 802.11ax | 1.775 Gbps device rate | Dual-radio | 48 access users recommended | Max. 128 access users | 20 dBm transmit power | Smart antenna | 10 m optimal coverage range

    AP160 Huawei eKit Product Specification

    Product Overview

    Huawei eKit AP160 Wall-Plate Wireless Access Point 802.11ax ความเร็วสูงสุด 1.775Gbps, Dual-radio 2.4/5GHz, Smart antenna, รองรับ POE มาตรฐาน 802.3af

    รองรับการ Managed ผ่าน Cloud/Stanalone

    Technical specifications

    Installation Type

    Junction Box

    Dimensions (Diameter x Height)

    86 mm x 86 mm x 42.5 mm

    Weight

    0.14 kg

    LED indicator

    Indicates the power-on, startup, running, alarm, and fault states of the system.

    Maximum power consumption [W]

    9.1

    Power supply mode

    PoE

    Rated input voltage [V]

    -

    Input voltage range [V]

    PoE: 802.3af

    Service port surge protection [kV]

    PoE port: Common mode (8 wires to ground): 4 kV (1.2/50 us, 42 ohms), criterion C

    Physical ports on the entire device

    GE (RJ45) x 2, 10M/100M/1000M auto-sensing

    Operating temperature

    -10°C to +40°C

    Storage temperature

    -40°C to +70°C

    Radio specifications

    Radio number

    2

    Operating frequency band

    2.4GHz,5GHz

    MIMO spatial streams

    -

    Wi-Fi standard

    2.4 GHz: 802.11b/g/n/ax
    5 GHz: 802.11a/n/ac/ac Wave 2/ax

    Antenna type

    Built-in smart antennas

    Antenna gain

    2.4 GHz: 3 dBi
    5 GHz: 2 dBi

    Maximum transmit power

    2.4G: 20 dBm (combined power)
    5G: 20 dBm (combined power)

    Maximum number of SSIDs for each radio

    6

    Maximum number of users

    ≤ 128
    NOTE: The actual number of users varies according to the environment.

    Cloud-based management mode

    WLAN features

    Compliance with IEEE 802.11ax and compatibility with IEEE 802.11a/b/g/n/ac/ac Wave 2
    Maximum ratio combining (MRC)
    Space time block code (STBC)
    Cyclic Delay Diversity (CDD)/Cyclic Shift Diversity (CSD)
    Beamforming
    Multi-user multiple-input multiple-output (MU-MIMO)
    Orthogonal frequency division multiple access (OFDMA)
    Compliance with 1024-quadrature amplitude modulation (QAM) and compatibility with 256-QAM, 64-QAM, 16-QAM, 8-QAM, quadrature phase shift keying (QPSK), and binary phase shift keying (BPSK)
    Target wake time (TWT)
    Low-density parity-check (LDPC)
    Frame aggregation, including A-MPDU (Tx/Rx) and A-MSDU (Tx/Rx)
    802.11 dynamic frequency selection (DFS)
    Priority mapping and scheduling that are compliant with Wi-Fi multimedia (WMM) to implement priority-based data processing and forwarding
    Automatic and manual rate adjustment (the rate is adjusted automatically by default)
    WLAN channel management and channel rate adjustment
    NOTE
    For detailed management channels, see the Country Codes & Channels Compliance.
    Automatic channel scanning and interference avoidance
    Service set identifier (SSID) hiding
    Signal sustain technology (SST)
    Unscheduled automatic power save delivery (U-APSD)

    Network features

    Compliance with IEEE 802.3ab
    Auto-negotiation of the rate and duplex mode and automatic switchover between the Media Dependent Interface (MDI) and Media Dependent Interface Crossover (MDI-X)
    Compliance with IEEE 802.1q
    SSID-based VLAN assignment
    DHCP client, obtaining IP addresses through DHCP
    STA isolation in the same VLAN
    Access control lists (ACLs)
    Unified authentication on the Cloud management platform
    Network Address Translation (NAT)

    QoS features

    Priority mapping and scheduling that are compliant with WMM to implement priority-based data processing and forwarding
    WMM parameter management for each radio
    WMM power saving
    Priority mapping for upstream packets and flow-based mapping for downstream packets
    Queue mapping and scheduling
    User-based bandwidth limiting
    Airtime scheduling
    Air interface HQoS scheduling

    Security features

    Open system authentication
    WEP authentication/encryption using a 64-bit, 128-bit, 152-bit or 192-bit encryption key
    WPA2-PSK authentication and encryption (WPA2-Personal)
    WPA2-802.1X authentication and encryption (WPA2-Enterprise)
    WPA3-SAE authentication and encryption (WPA3-Personal)
    WPA3-802.1X authentication and encryption (WPA3- Personal)
    WPA-WPA2 hybrid authentication
    WPA2-WPA3 hybrid authentication
    802.1X authentication, MAC address authentication, and Portal authentication
    DHCP snooping
    Dynamic ARP Inspection (DAI)
    IP Source Guard (IPSG)

    Maintenance features

    Unified management and maintenance on the Cloud management platform
    Automatic login and configuration loading, and plug-and-play (PnP)
    Batch upgrade
    Telnet
    STelnet using SSHv2
    SFTP using SSHv2
    Web-based local AP management through HTTP or HTTPS
    Real-time configuration monitoring and fast fault locating using the NMS
    System status alarm
    Network Time Protocol (NTP)

    รับประกัน

    3 ปี



    รายละเอียดสินค้า
    50 รายการ

    ข้อมูลสินค้า

    ลักษณะงาน Wireless
    กระจายสัญญาณ WIFI
    ความเร็ว มาตรฐาน WIFI
    WIFI-6 (ax) 1.7Gbps+
    ย่านความถี่
    Dual-Band 2.4/5GHz
    รองรับ Controller
    Cloud Controller
