6 x 10/100/1000BASE-T ports(PoE+) 2 x 10/100/1000BASE-T ports 2 x 10M/100M/GE/2.5GE BASE-T PoE+ ports (multi-GE ports)
Uplink port
2 x 10GE SFP+ ports 2 x 2.5GE SFP ports
Dimensions (H x W x D)
43.6 mm x 320 mm x 210 mm
Chassis height
1 U
Maximum power consumption
Without PoE: 24.03 W Full PoE load: 162.36 W (PoE: 128 W)
Rated input voltage
AC input: 100 V AC to 240 V AC, 50/60 Hz
Long-term operating temperature
–5°C to +40°C (0 m to 1800 m)
Storage temperature
–40°C to +70°C
Operating humidity
5% RH to 95% RH, non-condensing
Service Feature
MAC address entry
Complies with the IEEE 802.1d standard 16K MAC address entries at maximum Static, dynamic, and blackhole MAC address entries Automatic MAC address learning and aging
Link Aggregation Control Protocol (LACP) Storm control
QoS/ACL
Rate limiting on packets sent and received by an interface IPv4 access control list (ACL) Interface-based traffic policing Eight queues on each interface Packet filtering
Security features
Defense against DoS, ARP, and ICMP attacks Secure Boot Port isolation Blackhole MAC address entries AAA authentication CPU protection DHCP snooping
Management and maintenance
Cloud management Web system SSH v2.0 HTTPS LLDP System logs and multi-level alarms IEEE 802.3az Energy Efficient Ethernet (EEE) Port mirroring Deployment through the registration query center
