IP-COM G1124P-24-250W POE Switch 24 Port Gigabit POE 802.3af/at 225W รองรับ Port Isolate

Product Specification

Overview

IP-COM G1124P-24-250W POE Switch Giabit 24 Port แบบ Rack พร้อมหูยึดตู้ Rack
ความเร็ว Gigabit จ่ายไฟ POE มาตรฐาน 802.3af/at ได้ 24 Port สูงสุด 225W รองรับการทำ Port Isolate ง่ายๆ ด้วยการเลื่อน DIB Switch

Standard&Protocol

IEEE 802.3、IEEE 802.3u、IEEE 802.3x、IEEE 802.3ab、IEEE802.3af、IEEE802.3at

Indicator

24*Link/Act per device
24*PoE per device
1*Power per device

Interface

24 10/100/1000Base-T ports(Data/Power)

Port

Lightning Protection 6KV

Store and forward

Yes

Exchange Capacity

48 Gbps

Packet forwarding rate

35.7Mpps

MAC Address Table

8K

PoE supply management

Port 1-24 support IEEE802.3at/af PoE standard

PoE through pin

1 2 4 5 +;3 6 7 8 -

Voltage input range

AC: 100-240V～50/60Hz

Dimensions

440*178*44mm( W x D x H )

Power Consumption

in full configuration:<250W
PoE Max Power Supply:225W

Port Features

Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other.
CCTV: the port cache is optimized and PoE ports 1-8 have higher priorities over the other ports. All the ports of the switch can communicate with each other.
VLAN: ports 1 to 22 are isolated from each other, but can communicate with ports 23 and 24 (uplink ports) respectively.
Isolation：ports 1 to 14 and ports 15 to 24 belong to two different VLAN.This mode can be used to isolate supervision network and wireless network to make them not interfere with each other.

Operating|Storage Temperature

0℃~40℃ (32℉~104℉) | -40℃~70℃ (-40℉~158℉)

Operating|Storage Humidity

10%~90% non-condensing | 5%~90% non-condensing

ประกัน

3 ปี
