IP-COM G5328P-24-410W L3-Managed Gigabit PoE Switch 24 Port, 4SFP 410W

Product Specification

Overview

IP-COM G5332P-24-410W L3-Managed Gigabit PoE Switch ขนาด 24 Port ความเร็ว Gigabit พร้อม 4 Port SFP
จ่ายไฟ POE 802/3af/at 8 Port 130W รองรับ Static Routing, VLAN

Standards

IEEE802.3, IEEE802.3u, IEEE802.3ab,IEEE802.3ad, IEEE802.3z, IEEE802.3x, IEEE802.1p, IEEE802.1q, IEEE802.1w, IEEE802.1d, IEEE802.1s, IEEE802.3af/at

LED indicators

One Link/Act or PoE LED indicator for each port
One Link/One Link/Act mode converting LED indicator for each device
One PoE mode converting LED indicator for each device
One PoE Max LED indicator for each device
One Power LED indicator for each device
One SYS LED indicator for each device

Interfaces

24 x 10/100/1000 Base-T Ethernet ports (Data/Power)
4 x 1000 Base-X SFP ports (Data)

Lightning protection

Port: 6kV
Power: 6kV

Forwarding mode

Store-and-forward

Switching capability

56Gbps

Packet forwarding rate

41.7Mpps

Buffer

12Mbit

MAC address table

16K

PoE power supply

Ports 1 to 24 support IEEE 802.3af/at standard PoE power supply1 2 4 5 +, and 3 6 7 8 -

Whole switch consumption

Whole switch consumption: <410W
Maximum PoE output power: 370 W

Input voltage

AC：100-240V～ 50/60Hz

Dimensions

440 mm x 284 mm x 44 mm(L*W*H)

Operating environment

Operating temperature: 0°C - 45℃
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%)RH, non-condensing
Storage humidity: (5% - 90%)RH, non-condensing

Certificates

CCC、FCC、CE、RoHS

PoE power supply management

Supports port PoE configuration and power supply with priority
Supports PoE over-temperature protection
Supports PoE scheduled management
Supports intelligent and graphical management and PoE-powered device detection (port status, power assignment and PoE-powered device status)

Security features

Supports ARP receiving limit
Supports unknown MAC address discard
Supports DoS attack defense
Supports 802.1x security authentication
Supports Radius authentication

VLAN

Supports IEEE 802.1Q VLAN
Supports VLAN Layer-3 interfaces
Supports three port modes: Access, Trunk and Hybrid

DHCP

Supports DHCP Relay
Supports DHCP Snooping
Supports Option 82 policy configuration

L3 Routing

Supports VLAN-based routing
Supports IPv4 static routing
Supports static ARP

Port aggregation

Supports static aggregation
Supports LACP dynamic aggregation

Spanning tree

Supports IEEE 802.1d STP (Spanning Tree Protocol)
Supports IEEE 802.1w RSTP (Rapid Spanning Tree Protocol)
Supports IEEE 802.1s MSTP (Multiple Spanning Tree Protocol)
Supports edge port
Supports BPDU statistics

Multicast

Supports IGMP Snooping V1/V2/V3
Supports port fast leave

Port Mirroring

Supports N: 1 port mirroring

QoS

Supports SP (Strict Priority)
Supports SWRR (Simple Weighted Round Robin)
Support WRR (Weighted Round Robin)
Supports 802.1p port trust mode
Supports DSCP port trust mode
Supports a maximum of 8 queue service quality mapping

ACL

Supports MAC ACL
Supports IP ACL

Loading and upgrade

Supports FTP/TFTP/HTTP upgrade
Supports configuration import and export

ประกัน

3 ปี
