Support FDD-LTE B1/B2/B3/B4/B5/B7/B8/B28 Support TDD-LTE B38/B39/B40/B41 Support TD-SCDMA: B34, B39 Support HSPA+/UMTS B1/B2/B5/B8 Support EV-DO: BC0 CDMA 1x: BC0 Support EDGE/GPRS/GSM 850/900/1800/1900MHz
1 x RS232/485 serial interface with built-in 15KV ESD Data bits:5, 6, 7, 8 bits Stop bits:1, 1.5 (optional), 2 bits Error detection: none, even parity, odd parity, SPACE (optional) and MARK (optional) Serial Port Rate: 2400~115200bits/s
LED Indicators
“PWR”, “Online”, “LAN”, “WAN/LAN”, “WIFI”
Antenna Interface
Cellular: Standard SMA female antenna interface, characteristic impedance: 50 Ω WIFI: Standard SMA male antenna interface, characteristic impedance: 50 Ω
SIM/UIM Slot
Standard SIM card slot, support 1.8V/3V SIM/UIM card, built-in 15KV ESD, support dual-SIM card option
Power Interface
Standard 3.5mm terminal block interface, with built-in phase-reversal and over-voltage protection
Reset Button
Can reset router’s configuration to default factory setting by this button
Input Voltage
DC 12V/1.5A
Accepted Range
DC 5~36V
Standby
95~135mA@12VDC
Communicating
165~220mA@12VDC
Casing
Metal casing, IP30 protection level, suitable for most industrial control applications.
