| Device Interfaces |
Eight 10/100 Fast Ethernet LAN ports |
| Advanced Features |
Green Ethernet
1.6 Gbps switching fabric
Auto MDI/MDIX crossover for all ports
Secure store-and-forward switching scheme
Compliance with IEEE802.3az EEE power saving
Full/half-duplex for Ethernet/Fast Ethernet speeds
IEEE 802.3x Flow Control
Plug-and-play installation
RoHS compliant
Supports 2048-byte Jumbo Frames |
| Protocol |
CSMA/CD |
| Data Transfer Rates |
Ethernet:
10 Mbps (half duplex)
20 Mbps (full duplex)
Fast Ethernet:
100 Mbps (half duplex)
200 Mbps (full duplex) |
| Transmission Method |
Store-and-forward |
| MAC Address Table |
2K |
| MAC Address Learning |
Automatic Update |
| Packet Filtering/Forwarding Rates |
Ethernet: 14,880 pps per port
Fast Ethernet: 148,800 pps per port |
| RAM Buffer |
96 KB per device |
| LED Indicators |
Per port: Link/Activity
Per device: Power |
| Media Interface Exchange |
Auto MDI/MDIX adjustment for all ports |
| Dimensions |
141.5 x 78.5 x 23.8 mm (5.57 x 3.09 x 0.94 inches) |
| Power |
5 V/0.55 A Power Adapter |
| Heat Dissipation |
Power On (Standby): AC input:2.0472 Btu/h
Maximum: AC input:7.47228 Btu/h |
| Power Consumption |
Power On (Standby): DC input: 0.36 watts, AC input: 0.6 watts
Maximum: DC input: 1.78 watts, AC input: 2.19 watts
Link Up: EEE mode: DC input: 0.75 watts AC input: 1.1. watts |
| Temperature |
Operating: 0 to 40 ?C (32 to 104 ?F)
Storage: -10 to 70 ?C (14 to 158 ?F) |
| Humidity |
Operating: 10% to 90% non-condensing
Storage: 5% to 90% non-condensing |
| MTBF |
2,137,319 hours |
| Certifications |
CE Class B
FCC Class B
cUL
CB
VCCI Class B |
|
