| Interface |
16 Ports 10/100/1000Mbps RJ45 (Auto Negotiation/Auto MDI/MDIX)
2 1000Mbps SFP Slots 1 Console Port |
| Network Media |
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
1000BASE-X: MMF, SMF 1000Base-L X:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m) |
| Fan Quantity |
Fan |
| Power Consumption |
350W (max. with PoE device connected) |
| Internal Power Supply |
DC 52V 6.8A AC 110~265V 50/60HZ |
| PoE Ports (RJ45) |
Standard: 802.3 af/at compliant
PoE Ports: Port1- Port16
Power Supply: 350W |
| Exchange Capacity |
32G |
| Packet Forwarding Rate |
23.8Mpps |
| Mac Address Table |
8K |
| Packet Buffer Memory |
4Mb |
| Jumbo Frame |
10240 Bytes |
| Dimensions |
440mm* 220mm*44mm（L*W*H） |
| Quality of Service |
Support 802.1p CoS/DSCP priority
Support 4 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow- based Rate Limiting |
| L2 Features |
IGMP Snooping V1/V2/V3
802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group)
Spanning Tree STP/RSTP/MSTP
Port isolation
BPDU filtering/guard
TC/Root protect
Loop back detection
802.3x Flow Control |
| VLAN |
Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs)
Port/ MAC/Protocol-based VLAN
Management VLAN configuration |
| Access Control List |
L2～L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID;
Time Range Based |
| Security |
IP-MAC-Port-VID Binding
IEEE 802.1X Port/MAC Based authentication, Radius,Guest VLAN
DoS Defence
Dynamic ARP inspection (DAI)
SSH v1/v2
SSL v2/v3/TLSv1
Port Security
Broadcast/Multicast/Unknown-unicast Storm Control |
| Management |
Web-based GUI and CLI management
SNMP v1/v2c/v3,compatible with public MIBs DHCP/BOOTP Client,DHCP Snooping,DHCP Option82
CPU Monitoring
Port Mirroring
Time Setting: SNTP
Integrated NDP/NTDP feature
Firmware Upgrade: TFTP & Web
System Diagnose: VCT
SYSLOG & Public MIBS |
|
Certification
|
CE, FCC, RoHS
|
|
Package Contents
|
POE Switch Electric Line
Guide Book/Warranty Card |
|
Environment
|
Working Temperature： 0℃～40℃ Storage temperature ： -40℃～70℃
Working Humidity ： 10%～90%
RH non-condensing
Storage Humidity：5%～90%
RH non-condensing |
|
รับประกัน
|
สินค้ารับประกัน 2 ปี
|
