AP9635 Access Point Product Specification |
Overview | TP-LINK AP9650 AX3000 Ceiling Mount WiFi 6 Access Point, Dual-Band 2.4/5GHz, Port LAN Gigabit, กระจายรอบทิศทาง บริหารจัดการผ่าน Omada Controller |
| HARDWARE FEATURES |
| Interface | 1× Gigabit Ethernet Port |
| Button | Reset |
| Power Supply | 48 V Passive PoE or 802.3at PoE or 12 V / 1.5 A DC |
| Power Consumption | • EU: 14.4 W (For PoE); 13.1 W (for DC)
• US: 14.9 W (For PoE); 13.4 W (for DC) |
| Dimensions ( W x D x H ) | 6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm) |
| Antenna Type | Internal Antennas
• 2.4 GHz: 2× 4 dBi
• 5 GHz: 2× 5 dBi |
| WIRELESS FEATURES |
| Wireless Client Capacity | 1,000+** |
| Wireless Standards | IEEE 802.11 a/b/g/n/ac/ax |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | • 5 GHz: Up to 1201 Mbps†
• 2.4 GHz: Up to 574 Mbps† |
| Wireless Functions | • Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
• Enable/Disable Wireless Radio
• Enable/Disable SSID Broadcast
• Guest Network
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS(WMM)
• Seamless Roaming△
• Mesh△
• Beamforming
• MU-MIMO
• OFDMA
• Rate Limit(Based on SSID/Client)
• Load Balance
• Airtime Fairness
• Band Steering
• RADIUS Accounting
• MAC Authentication
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics
• Static IP/Dynamic IP |
| Wireless Security | • Captive Portal Authentication△
• Access Control
• Maximum number of MAC Filter: 4,000
• Wireless Isolation Between Clients
• SSID VLAN
• WIDS/WIPS△
• Rogue AP Detection
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Transmission Power | • CE:
<20 dBm(2.4 GHz, EIRP)
<23 dBm(5 GHz Band 1&2, EIRP)
<30 dBm (5 GHz Band 3, EIRP) |
| MANAGEMENT |
| Omada App | Yes |
| Restore & Backup | Yes |
| Firmware update via Web | Yes |
| NTP | Yes |
| Centralized Management | • Omada Pro Software Controller
• Omada Pro Cloud-Based Controller |
| Cloud Access | Yes. Require the use of Omada Pro Cloud-Based Controller, or Omada Pro Software Controller. |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| System Logging Local/Remote Syslog | System Log |
| SSH | Yes |
| Web-based Management | Yes |
| Zero-Touch Provisioning | Yes. Require the use of Omada Pro Cloud-Based Controller |
| OTHERS |
| Certification | CE, FCC, RoHS |
| Package Contents | • AP9635
• Ceiling / Wall Mounting Kits
• Installation Guide |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Environment | • Operating Temperature: 0–40 ℃ (32–104 ℉)
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing |
รับประกัน | Limited lifetime |
|
|
