| Product Specification |
| Processor: |
1.8 GHz 64bit Quad-Core CPU |
| Memory: |
1 GB RAM and 512 MB Flash |
| Interface: |
8 1G/100M/10M LAN Ports, |
| 1 2.5G/1G/100M WAN Port |
| 1 USB-A 3.0 Port + 1 USB-C 3.0 Port |
| Button: |
Wi-Fi On/Off Button, Reset Button, WPS Button, Power On/Off Button, LED on/off Button |
| External Power Supply: |
12V/5A |
| Dimensions ( W x D x H ): |
11.3 × 11.3 × 7.2 in. (288 × 288 × 184mm) |
| Antenna: |
8 High-Performance External Antennas |
| WIRELESS FEATURES |
| Wireless Standards: |
IEEE 802.11ax/ac/n/a 5 GHz |
| IEEE 802.11ax/n/b/g 2.4 GHz |
| Frequency: |
2.4 GHz and 5 GHz |
| Signal Rate: |
5 GHz: 4804 Mbps(802.11ax) |
| 5 GHz: 4804 Mbps(802.11ax) |
| 2.4 GHz: 1148 Mbps(802.11ax) |
| compatible with 802.11a/b/g/n/ac Wi-Fi standards |
| Reception Sensitivity: |
5 GHz_1: |
| 11a 6Mbps：-96dBm, 11a 54Mbps:-78dBm |
| 11ac VHT20_MCS0:-95dBm, 11ac VHT20_MCS11:-65dBm |
| 11ac VHT40_MCS0:-93dBm, 11ac VHT40_MCS11:-62dBm |
| 11ac VHT80_MCS0:-90dBm, 11ac VHT80_MCS11:-59dBm |
| 11ac VHT160_MCS0:-87dBm, 11ac VHT160_MCS11:-54dBm |
| 11ax HE20_MCS0:-94dBm, 11ax HE20_MCS11:-62Bm |
| 11ax HE40_MCS0:-91dBm, 11ax HE40_MCS11:-59dBm |
| 11ax HE80_MCS0:-88dBm, 11ax HE80_MCS11:-57dBm |
| 11ax HE160_MCS0:-84dBm, 11ax HE160_MCS11:-54dBm |
| 5 GHz_2: |
| 11a 6Mbps：-96dBm, 11a 54Mbps:-78dBm |
| 11ac VHT20_MCS0:-95dBm, 11ac VHT20_MCS11:-65dBm |
| 11ac VHT40_MCS0:-93dBm, 11ac VHT40_MCS11:-62dBm |
| 11ac VHT80_MCS0:-90dBm, 11ac VHT80_MCS11:-59dBm |
| 11ac VHT160_MCS0:-87dBm, 11ac VHT160_MCS11:-54dBm |
| 11ax HE20_MCS0:-94dBm, 11ax HE20_MCS11:-62Bm |
| 11ax HE40_MCS0:-91dBm, 11ax HE40_MCS11:-59dBm |
| 11ax HE80_MCS0:-88dBm, 11ax HE80_MCS11:-57dBm |
| 11ax HE160_MCS0:-84dBm, 11ax HE160_MCS11:-54dBm |
| 2.4 GHz： |
| 11g 6Mbps：-97dBm, 11a 54Mbps:-79dBm |
| 11n HT20_MCS0:-97dBm, 11n HT20_MCS7:-78dBm |
| 11n HT40_MCS0:-95dBm, 11n HT40_MCS7:-75dBm |
| 11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-67dBm |
| 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-64dBm |
| 11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-64dBm |
| 11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-61dBm |
| Wireless Functions: |
Enable/Disable Wireless Radio, Guest network, DFS, MU-MIMO, OFDMA |
| Wireless Security: |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
| Transmission Power: |
CE: <20dBm(2.4GHz), <23dBm(5.15GHz~5.35GHz); <30dBm(5.47GHz~5.725GHz) |
| FCC: <30dBm(2.4GHz & 5.15GHz~5.25GHz & 5.725GHz~5.825GHz), <24dBm(5.25GHz-5.35GHz & 5.47GHz-5.725 GHz) |
| Guest Network: |
2.4 GHz guest network0 × 1, 5 GHz guest network × 1 |
