Product Specification |
Over View | TP-Link Archer AX55 AX3000 Dual Band Gigabit Wi-Fi 6 Router พร้อม 4 Port Lan Gigabit เสาอากาศ 4 ต้น Beamforming |
WIRELESS |
|---|
Standards | Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz |
|---|
WiFi Speeds | AX3000
5 GHz: 2402 Mbps (802.11ax, HE160)
2.4 GHz: 574 Mbps (802.11ax) |
|---|
WiFi Range | 3 Bedroom Houses
4× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range
High-Power FEM
Improves transmission power to strengthen signal coverage |
|---|
WiFi Capacity | High
Dual-Band
Allocate devices to different bands for optimal performance
OFDMA
Simultaneously communicates with multiple Wi-Fi 6 clients
Airtime Fairness
Improves network efficiency by limiting excessive occupation
DFS
Access an extra band to reduce congestion
4 Streams
Connect your devices to more bandwidth |
|---|
Working Modes | Router Mode
Access Point Mode |
|---|
HARDWARE |
|---|
Processor | Dual-Core CPU |
|---|
Ethernet Ports | 1× Gigabit WAN Port
4× Gigabit LAN Ports |
|---|
USB Support | 1× USB 3.0 Port
Supported Partition Formats:
NTFS, exFAT, HFS+, FAT32
Supported Functions:
Apple Time Machine
FTP Server
Media Server
Samba Server |
|---|
Buttons | Wi-Fi/WPS Button
Power On/Off Button
Reset Button |
|---|
Power | 12 VDC 2 A |
|---|
SECURITY |
|---|
WiFi Encryption | WPA
WPA2
WPA3
WPA/WPA2-Enterprise (802.1x) |
|---|
Network Security | SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner |
|---|
Guest Network | 1× 5 GHz Guest Network
1× 2.4 GHz Guest Network |
|---|
VPN Server | OpenVPN
PPTP |
|---|
SOFTWARE |
|---|
Protocols | IPv4
IPv6 |
|---|
Service Kits | HomeShield
Learn More> |
|---|
OneMesh™ | OneMesh™ Supported
Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
Learn More>
All OneMesh Products> |
|---|
Parental Controls | HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports |
|---|
WAN Types | Dynamic IP
Static IP
PPPoE
PPTP
L2TP |
|---|
Quality of Service | QoS by Device |
|---|
Cloud Service | Auto Firmware Upgrade
OTA Firmware Upgrade
TP-Link ID
DDNS |
|---|
NAT Forwarding | Virtual Servers
Port Forwarding
Port Triggering
DMZ
UPnP |
|---|
IPTV | IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN |
|---|
DHCP | Address Reservation
DHCP Client List
Server |
|---|
DDNS | TP-Link
NO-IP
DynDNS |
|---|
Management | Tether App
Webpage
Check Web Emulator> |
|---|
PHYSICAL |
|---|
Dimensions (W×D×H) | 10.2 × 5.3 × 1.5 in
(261.1 × 134.5 × 41.0 mm) |
|---|
Package Contents | Wi-Fi Router Archer AX55
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide |
|---|
OTHER |
|---|
System Requirements | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access) |
|---|
Certifications | FCC, CE, RoHS |
|---|
Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing |
|---|
TEST DATA |
|---|
WiFi Transmission Power | CE:
<20dBm(2.4GHz)
<23dBm(5.15GHz~5.35GHz)
<30dBm(5.47GHz~5.725GHz)
FCC:
<30dBm(2.4GHz & 5.15GHz~5.825GHz) |
|---|
WiFi Reception Sensitivity | 5GHz:
11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS8:-75dBm
11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS9:-70dBm
11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS9:-67dBm
11ac VHT160_MCS0:-88dBm, 11ac VHT160_MCS9:-63dBm
11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-66dBm
11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-63dBm
11ax HE80_MCS0:-91dBm, 11ax HE80_MCS11:-61dBm
11ax HE160_MCS0:-87dBm, 11ax HE160_MCS11:-58dBm
2.4GHz:
11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS8:-74dB
11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS9:-70dB
11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-66dBm
11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-63dBm |
|---|
รับประกัน | Life Time |
