TP-Link EAP620
HDAX1800 Wireless Dual Band Ceiling Mount Access Point
- Ultra-Fast Wi-Fi 6 Speeds:Simultaneous 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz totals 1775 Mbps Wi-Fi speeds.†
- High-Density Connectivity: 4× increased capacity to connect more devices simultaneously.‡
- Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)§, Centralized Cloud Management, and Intelligent Monitoring.
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
- Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.△
- PoE+ Support:Supports Power over Ethernet (802.3at) for convenientdeployment and installation.
- Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.
Product Specification |
Overview | TP-LINK EAP620 HD Wireless Access Point มาตรฐาน WIFI6 AX1800 เสาภายใน 2x5dBi 5GHz, 2x4dBi 2.4GHz กระจายรอบทิศทาง รองรับ Omada SDN Controller Software |
|
|---|
Interface | 1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE and Passive PoE) |
|---|
Button | Reset |
|---|
Power Supply | • 802.3at PoE
• 48 V Passive PoE
• 12 V / 1.5 A DC |
|---|
Power Consumption | • EU: 14.4 W (For PoE); 13.1 W (for DC)
• US: 14.9 W (For PoE); 13.4 W (for DC)
|
|---|
Dimensions ( W x D x H ) | 6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm) |
|---|
Antenna Type | Internal Omni Antenna
• 2.4 GHz: 2× 4 dBi
• 5 GHz: 2× 5 dBi |
|---|
Mounting | • Ceiling /Wall Mounting (Kits included)
• Junction Box Mounting |
|---|
|
|---|
Wireless Standards | IEEE 802.11ax/ac/n/g/b/a |
|---|
Frequency | 2.4 GHz and 5 GHz |
|---|
Signal Rate | • 5 GHz: Up to 1201 Mbps
• 2.4 GHz: Up to 574 Mbps
|
|---|
Wireless Functions | • 1024-QAM
• 4× Longer OFDM Symbol
• OFDMA
• Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS(WMM)
• MU-MIMO
• Seamless Roaming
• Omada Mesh
• Band Steering
• Load Balance
• Airtime Fairness
• Beamforming
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client |
|---|
Wireless Security | • Captive Portal Authentication△
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
• WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
|---|
Transmission Power | • CE:
<20 dBm(2.4 GHz, EIRP)
<23 dBm(5 GHz band1/2, EIRP) <25 dBm (5 GHz band3)
• FCC:
<25 dBm (2.4 GHz)
<25 dBm (5 GHz) |
|---|
|
|---|
Omada App | Yes |
|---|
Centralized Management | • Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller |
|---|
Cloud Access | Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) |
|---|
Email Alerts | Yes |
|---|
LED ON/OFF Control | Yes |
|---|
Management MAC Access Control | Yes |
|---|
SNMP | v1, v2c, v3 |
|---|
System Logging Local/Remote Syslog | Local/Remote Syslog |
|---|
SSH | Yes |
|---|
Web-based Management | HTTP/HTTPS |
|---|
L3 Management | Yes |
|---|
Multi-site Management | Yes |
|---|
Management VLAN | Yes |
|---|
|
|---|
Certification | CE, FCC, RoHS |
|---|
Package Contents | • EAP620 HD
• Power Adapter
• Ceiling / Wall Mounting Kits
• Installation Guide
|
|---|
System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux |
|---|
Environment | • Operating Temperature: 0–40 ℃ (32–104 ℉)
• Storage Temperature: -40–70 ℃ (-40–158 ℉)
• Operating Humidity: 10–90% RH non-condensing
• Storage Humidity: 5–90% RH non-condensing |
|---|
รับประกัน | Limited lifetime |
รายละเอียดสินค้า
20 รายการ
ข้อมูลสินค้า
- ลักษณะงาน Wireless
- กระจายสัญญาณ WIFI
- ความเร็ว มาตรฐาน WIFI
- WIFI-6 (ax) 1.7Gbps+
- ย่านความถี่
- Dual-Band 2.4/5GHz
- รองรับ Controller
- Hardware Controller
- รองรับ POE
- Yes
