Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q,
IEEE 802.1p |
|---|
Interface | 24 10/100Mbps RJ45 Ports
(Auto Negotiation/Auto MDI/MDIX)
4 10/100/1000Mbps RJ45 Ports
(Auto Negotiation/Auto MDI/MDIX)
2 Combo Gigabit SFP Slots |
|---|
Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP category 5, 5e or above cable
(maximum 100m)
1000BASE-X: MMF, SMF |
|---|
Fan Quantity | 2 |
|---|
Power Supply | 100~240VAC, 50/60Hz |
|---|
Power Consumption | Maximum(PoE on): 222.2W |
|---|
PoE Budget | 192W |
|---|
PoE+ Ports(RJ45) | Standard: 802.3at/af compliant
PoE+ Ports: 24 Ports
Power Supply: 180W |
|---|
Dimensions ( W x D x H ) | 17.3 x 7.1 x 1.7 in.
(440*220*44 mm) |
|---|
Bandwidth/Backplane | 12.8Gbps |
|---|
Packet Forwarding Rate | 9.5Mpps |
|---|
MAC Address Table | 8k |
|---|
Jumbo Frame | 9216 Bytes |
|---|
Quality of Service | Support 802.1p CoS/DSCP priority
Support 4 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow-based Rate Limiting
Voice VLAN |
|---|
L2 Features | IGMP Snooping V1/V2/V3
802.3ad LACP (Up to 6 aggregation groups, containing 4 ports per group)
Spanning Tree STP/RSTP/MSTP
BPDU Filtering/Guard
TC/Root Protect
Loop back detection
802.3x Flow Control
LLDP, LLDP-MED |
|---|
VLAN | Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs) |
|---|
Access Control List | L2~L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports |
|---|
Security | Port Security
DHCP Snooping
IP-MAC-Port Binding
ARP Inspection
802.1x and Radius Authentication
SSH v1/v2
SSL v3/TLSv1
Broadcast/Multicast/Unknown-unicast Storm Control
Dos Defend
|
|---|
Management | Web-based GUI
Command Line Interface(CLI) through telnet
SNMP v1/v2c/v3,compatible with public MIBs and
TP-Link private MIBs
RMON (1, 2, 3, 9 groups)
CPU Monitoring
Port Mirroring
Time Setting: SNTP
Firmware Upgrade: TFTP & Web
System Diagnose: VCT
SYSLOG & Public MIBS
Dual Image
|
|---|
Certification | CE, FCC, RoHS |
|---|
Package Contents | T1500-28PCT
Power Cord
Installation Guide
Resource CD
Rackmount Kit
Rubber Feet |
|---|
System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8, MAC OS, NetWare, UNIX or Linux. |
|---|
Environment | Operating Temperature: 0~40C (32~104F);
Storage Temperature: -40~70C (-40~158F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
|---|
รับประกัน | Limited lifetime |
