TP-Link TD-W9970 VDSL2/ ADSL Modem Router ความถี่ 2.4Ghz ความเร็ว 300Mbps 4 Port Lan

Product Specification

Overview

TP-Link TD-W9970 300Mbps Wireless N USB VDSL2 Modem Router กระจายสัญญาณ Wireless ความถี่ 2.4GHz ความเร็วสูงสุด 300 Mbps 4 Port Lan,1 Port VDSL/ADSL อุปกรณ์ All In One ราคาประหยัด

รองรับ Internet ทั้งแบบ VDSL และ ADSL

IEEE Standards

IEEE 802.3, 802.3u

VDSL2 Standards

ITU-T G.993.2
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP)

ADSL Standards

Full-rate ANSI T1.413 Issue 2
ITU-T G.992.1(G.DMT)
ITU-T G.994.1 (G.hs)
ITU-T G.995.1

ADSL2 Standards

ITU-T G.992.3 (G.dmt.bis)

ADSL2+ Standards

ITU-T G.992.5

Wireless Standards

IEEE 802.11b, 802.11g, 802.11n รองรับความเร็วสูงสุด 300Mbps

Frequency

2.400-2.4835GHz

Transmit Power

< 20dBm (EIRP)

Wireless Security

Support 64/128 bit WEP, WPA /WPA2, WPA-PSK/WPA2-PSK
Wireless MAC Filtering

เสาอากาศ

เสากระจายสัญญาณรอบทิศทาง 2 ต้น Gain 5dBi ไม่สามารถปรับเปลี่ยนได้

Quality of Service

WMM, Bandwidth Control (IP QoS)

Security

NAT Firewall,
SPI Firewall,
MAC / IP / URL Filtering

IPv6

IPv6 and IPv4 dual stack
Supported IPv6 Tunnels: DS-Lite, 6RD, 6 to 4
Supported IPv6 Connection Type: PPPoEv6, DHCPv6, Static IPv6

Management

Web Based Configuration(HTTP),
Remote management,
Telnet management,
Command Line Interface,
SSL for TR-069,
SNMP V1/V2C,
Web Based Firmware Upgrade,
CWMP(TR-069),
Diagnostic Tools

Port Forwarding

Virtual server, Port Triggering, UPnP, DMZ, Manage Control

VPN Pass-Through

PPTP, L2TP, IPSec Pass-through

ATM/PPP Protocols

ATM Forum UNI3.1/4.0
PPP over ATM (RFC 2364)
PPP over Ethernet (RFC2516)
IPoA (RFC1577/2225)
PVC - Up to 8 PVCs

Advanced Features

Ethernet WAN (EWAN)
Guest Network, Wireless Schedule
Parent Control
Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt;
Dynamic Host Configuration Protocol (DHCP), DHCP relay;
Network Address Translation (NAT);
PVC/Ethernet Port Grouping
Static Routing, RIP v1/v2 (optional);
DNS Relay, DDNS,
IGMP snooping V1/2
IGMP Multicast,
UPnP

USB Sharing

Storage Sharing
FTP Server
Media Server
Print Server

IGMP

IGMP snooping V1/V2/V3
IGMP Multicast

IPSec VPN

10 IPSec VPN Tunnels
LAN-to-LAN
Main, Aggressive Negotiation Mode
DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
MD5, SHA1 Authentication Algorithm
Manual, IKE Key Management Mode
Dead Peer Detection (DPD)
Perfect Forward Secrecy (PFS)

Environment

Operating Temperature: 0~40 (32~104)
Storage Temperature: -40~70 (-40~158)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Interfaces

4 10/100Mbps RJ45 Ports
1 RJ11 Port
1 USB 2.0 Port

Button

1 Power On/Off Button
1 WPS/RESET Button
1 Wi-Fi On/Off Switch

W x H x D

195 x 130 x 36mm

Weight

-

Power

12VDC / 1A

สินค้ารับประกัน Life Time
