    TL-SG1016DE TP-LINK Easy Smart Gigabit Switch Rackmount 16 port Gigabit
    • TL-SG1016DE TP-LINK Easy Smart Gigabit Switch Rackmount 16 port Gigabit
    • TL-SG1016DE TP-LINK Easy Smart Gigabit Switch Rackmount 16 port Gigabit
    • TL-SG1016DE TP-LINK Easy Smart Gigabit Switch Rackmount 16 port Gigabit
    • TL-SG1016DE TP-LINK Easy Smart Gigabit Switch Rackmount 16 port Gigabit

    TL-SG1016DE TP-LINK Easy Smart Gigabit Switch Rackmount 16 port Gigabit

    TP-Link

    TL-SG1016DE

    TP-Link TL-SG1016DE Easy Smart Gigabit Switch Rackmount 16 Port ความเร็ว Gigabir เคสเหล็ก รองรับการทำ VLAN ,Network Monitoring และ Traffic Prioritization

    ฿3,100.00
    ยังไม่ได้รวมภาษี
    จำนวน
    2 รายการ


    Support / ติดตั้งด้วยทีมงาน
    Certificate


    สอบถามข้อมูลสินค้าเพิ่มเติม

    LINE ID: @sysnet  โทร: 02 102 4284

    Click ต้องการใบเสนอราคา

    close

    แบบฟอร์มขอใบเสนอราคา



    Rating:
    (0)
    รายละเอียด

    TP-LINK TL-SG1016DE Datasheet
    TP-LINK TL-SG1016DE Easy Smart Configulation Utility User Guide
    TP-LINK TL-SG1016DE Install Guide.

    TL-SG1016DE

    16-Port Gigabit Easy Smart Switch

    • 16 10/100/1000Mbps RJ45 ports
    • Provides network monitoring, traffic prioritization and VLAN features
    • Green technology reduces power consumption
    • Simple network set-up on top of plug-and-play connectivity
    • Web-based user interface and management utility simplify configuration

    Product Specification

    Overview

    TP-Link TL-SG1016DE Easy Smart Gigabit Switch Rackmount 16 Port ความเร็ว Gigabir เคสเหล็ก รองรับการทำ VLAN ,Network Monitoring และ Traffic Prioritization

    HARDWARE FEATURES

    Standards and Protocols

    IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p

    Interface

    16 10/100/1000Mbps RJ45 Ports
    AUTO Negotiation/AUTO MDI/MDIX

    Network Media

    10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
    EIA/TIA-568 100Ω STP (maximum 100m)
    100BASE-TX: UTP category 5, 5e cable (maximum 100m)
    EIA/TIA-568 100Ω STP (maximum 100m)
    1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
    EIA/TIA-568 100Ω STP (maximum 100m)

    Fan Quantity

    Fanless

    Physical Security Lock

    No

    Power Supply

    100-240VAC, 50/60Hz

    Dimensions ( W x D x H )

    11.6*7.1*1.7 in. (294*180*44 mm)

    Mounting

    Rack Mountable

    Max Power Consumption

    10.22W (220V/50Hz)

    Max Heat Dissipation

    34.52 BTU/h

    PERFORMANCE

    Switching Capacity

    32Gbps

    Packet Forwarding Rate

    23.8Mpps

    MAC Address Table

    8K

    Packet Buffer Memory

    4.1Mbit

    Jumbo Frame

    10KB

    SOFTWARE FEATURES

    Quality of Service

    Support Port-based/802.1p/DSCP priority
    Support 4 priority queues
    Rate Limit
    Storm Control

    L2 Features

    IGMP Snooping V1/V2/V3
    Static Link Aggregation
    Port Mirroring
    Cable Diagnostics
    Loop Prevention

    VLAN

    Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
    MTU/Port/Tag VLAN

    Transmission Method

    Store-And-Forward

    OTHERS

    Certification

    FCC, CE, RoHS

    Package Contents

    TL-SG1016DE
    Power Cord
    Installation Guide
    Resource CD
    Rackmount Kit
    Rubber Feet

    System Requirements

    Microsoft® Windows® for running Utility

    Environment

    Operating Temperature: 0℃~40℃ (32℉~104℉)
    Storage Temperature: -40℃~70℃ (-40℉~158℉)
    Operating Humidity: 10%~90% non-condensing
    Storage Humidity: 5%~90% non-condensing

    Warranty

    Lifetime



    รายละเอียดสินค้า
    2 รายการ

    ข้อมูลสินค้า

    Switches Layer
    UnManaged
    จำนวน Port Lan
    16 Port
    ความเร็ว Port Lan
    1Gbps (Gigabit)
