Standards and Protocols
|
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
|
|
Interface
|
5 Port 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
|
|
Network Media
|
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100? STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100? STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100? STP (maximum 100m)
|
|
Fan Quantity
|
Fanless
|
|
Power Supply
|
External Power Adapter(Output: 9VDC/0.6A)
|
|
Power Consumption
|
Maximum: 2.49W (220V/50Hz)
|
|
Dimensions ( W x D x H )
|
3.9 * 3.9 *1.0 in. (100 * 98 *25 mm)
|
|
Packet Forwarding Rate
|
7.4Mpps
|
|
MAC Address Table
|
2K
|
|
Packet Buffer Memory
|
1Mb
|
|
Jumbo Frame
|
15KB
|
|
Quality of Service
|
Support Port-based/802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control
|
|
L2 Features
|
IGMP Snooping V1/V2/V3
Static Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention
|
|
VLAN
|
Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN
|
|
Transmission Method
|
Store-And-Forward
|
|
Certification
|
FCC, CE, RoHS
|
|
Package Contents
|
TLSG105E
Power Adapter
Installation Guide
Rubber Feet
|
|
System Requirements
|
Microsoft Windows for running Utility
|
|
Environment
|
Operating Temperature: 0~40C (32~104F)
Storage Temperature: -40~70C (-40~158F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
|
|
รับประกัน
|
Limited lifetime
|
