Interface
|
16 PoE+ 10/100Mbps RJ45 Ports
2 10/100/1000Mbps RJ45 Ports
2 Combo Gigabit SFP Slots
|
|
Media Interface Exchange
|
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-X MMF, SMF
|
|
Fan Quantity
|
2 Fans
|
|
Physical Security Lock
|
Yes
|
|
Power Supply
|
100-240V AC, 50/60 Hz
|
|
Backup Bandwidth
|
7.2 Gbps
|
|
PoE+ Ports(RJ45)
|
Standard: 802.3at/802.3af compliant
PoE Ports: Port1- Port16
PoE Power Budget: 192W
|
|
Mac Address Table
|
8K
|
|
Dimensions ( W x D x H )
|
17.3 × 7.1 × 1.7 in. (440 × 180 × 44 mm)
|
|
Max Power Consumption
|
18.73 W (220/50Hz. no PD connected)
217.22 W (220/50Hz. with 192W PD connected)
|
|
Max Heat Dissipation
|
63.89 BTU/h (no PD connected)
741.15 BTU/h (with 192W PD connected)
|
|
Advanced Features
|
Compatible With IEEE 802.3at/af Compliant PDs
Port Priority Mode
Extend Mode (Up to 250m PoE power supply and data transmission)
Mac Address Auto-Learning And Auto-Aging
IEEE802.3x Flow Control
|
|
Transmission Method
|
Store-And-Forward
|
|
Certification
|
CE, FCC, RoHS
|
|
Package Contents
|
TL-SL1218MP, Power Cable, Installation Guide, Two mounting brackets and the fittings
|
|
Environment
|
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5%~90% non-condensing
|
|
รับประกัน
|
Limited lifetime
|
