Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab,
IEEE802.3z, IEEE 802.3x, IEEE 802.1d,
IEEE 802.1s, IEEE 802.1w, IEEE 802.1q,
IEEE 802.1p |
|---|
Interface | 8 10/100Mbps RJ45 Ports
(Auto-Negotiation /Auto MDI/MDIX)
1 10/100/1000Mbps RJ45 Port
1 Gigabit SFP Slot |
|---|
Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP category 5, 5e or above cable
(maximum 100m)
1000BASE-X: MMF, SMF |
|---|
Fan Quantity | Fanless |
|---|
Power Supply | 100~240VAC, 50/60Hz |
|---|
Power Consumption | Maximum: 4.9W (220V/50Hz) |
|---|
Dimensions ( W x D x H ) | 11.6 * 7.1 * 1.7 in. (294 * 180 * 44 mm) |
|---|
PERFORMANCE |
|---|
Bandwidth/Backplane | 5.6Gbps |
|---|
Packet Forwarding Rate | 4.2Mpps |
|---|
MAC Address Table | 8k |
|---|
Packet Buffer Memory | 4.1Mb |
|---|
Jumbo Frame | 10KB |
|---|
SOFTWARE FEATURES |
|---|
Quality of Service | Support 802.1p CoS/DSCP priority
Support 4 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow-based Rate Limiting
Voice VLAN |
|---|
L2 Features | IGMP Snooping V1/V2/V3
802.3ad LACP (Up to 6 aggregation groups,
containing 4 ports per group)
Spanning Tree STP/RSTP/MSTP
BPDU Filtering/Guard
TC/Root Protect
Loop back detection
802.3x Flow Control |
|---|
VLAN | Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs) |
|---|
Access Control List | L2~L4 package filtering based on source and destination
MAC address, IP address, TCP/UDP ports, 802.1p,
DSCP, protocol and VLAN ID
Time Range Based |
|---|
Security | SSH v1/v2
SSL v2/v3/TLSv1
Port Security
Broadcast/Multicast/Unknown unicast Storm Control |
|---|
Management | Web-based GUI and CLI management
SNMP v1/v2c/v3, compatible with public MIBs and TP-LINK private MIBs
RMON (1, 2, 3, 9 groups)
CPU Monitoring
Port Mirroring
Time Setting: SNTP
Firmware Upgrade: TFTP & Web
System Diagnose: VCT
SYSLOG & Public MIBS |
|---|
OTHERS |
|---|
Certification | CE, FCC, RoHS |
|---|
Package Contents | TL-SL2210
Power Cord
Installation Guide
Resource CD
Rackmount Kit
Rubber Feet |
|---|
System Requirements | Microsoft Windows 8/7/Vista/XP, Mac OS or Linux-based operating system |
|---|
Environment | Operating Temperature: 0~40C (32~104F);
Storage Temperature: -40~70C (-40~158F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
|---|
