TP-LINK TL-WR841N Product Specification |
Overview | TP-LINK TL-WR841N Wireless N Router 2.4GHz 300Mbps 2.5dBi x 2 Antenna, 4 Port Lan, 1 Port Lan 100Mbps |
HARDWARE FEATURES |
|---|
Interface | 4 10/100Mbps LAN PORTS
1 10/100Mbps WAN PORT |
|---|
Ports | 4 ? 10/100Mbps LAN Ports, 1 ? 10/100Mbps WAN Port |
|---|
Button | WPS/Reset Button |
|---|
External Power Supply | 9VDC / 0.6A |
|---|
Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
|---|
Dimensions ( W x D x H ) | 6.9 x 4.6 x 1.3 in. (173 x 118 x 33mm) |
|---|
Antenna | 2*5dBi Fixed Omni Directional Antenna |
|---|
WIRELESS FEATURES |
|---|
Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
|---|
Frequency | 2.4-2.4835GHz |
|---|
Signal Rate | 11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic) |
|---|
Reception Sensitivity | 270M: -70dBm@10% PER
130M: -74dBm@10% PER
108M: -74dBm@10% PER
54M: -77dBm@10% PER
11M: -87dBm@8% PER
6M: -90dBm@10% PER
1M: -98dBm@8% PER |
|---|
Transmit Power | CE:
<20dBm
FCC:
<30dBm |
|---|
Wireless Functions | Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
|---|
Wireless Security | 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK |
|---|
SOFTWARE FEATURES |
|---|
Quality of Service | WMM, Bandwidth Control |
|---|
WAN Type | Dynamic IP/Static IP/PPPoE/
PPTP/L2TP/BigPond |
|---|
Management | Access Control
Local Management
Remote Management |
|---|
DHCP | Server, Client, DHCP Client List,
Address Reservation |
|---|
Port Forwarding | Virtual Server,Port Triggering, UPnP, DMZ |
|---|
Dynamic DNS | DynDns, Comexe, NO-IP |
|---|
VPN Pass-Through | PPTP, L2TP, IPSec (ESP Head) |
|---|
Access Control | Parental Control, Local Management Control, Host List, Access Schedule, Rule Management |
|---|
Firewall Security | DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding |
|---|
Protocols | Support IPv4 and IPv6 |
|---|
Guest Network | 2.4GHz Guest Network x1 |
|---|
Working Modes | Wireless Router, Range Extender, Access Point, WISP |
|---|
OTHERS |
|---|
Certification | CE, FCC, RoHS |
|---|
Package Contents | Wireless Router TL-WR841N
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide |
|---|
System Requirements | Microsoft? Windows? 10/8.1/8/7/Vista/XP/2000/NT/98SE,
MAC? OS, NetWare?, UNIX? or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Cable or DSL Modem
Subscription with an internet service provider (for internet access) |
|---|
Environment | Operating Temperature: 0?~40? (32?~104?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
|---|
รับประกัน | Limited lifetime |
|
|
