APC BR650MI UPS Product Datasheet
APC BR650MI UPS User Manual
|
Main Input Voltage |
230 V |
|---|---|
|
Rated power in W |
390 W |
|
Rated power in VA |
650 VA |
|
Product or component type |
Uninterruptible power supply (UPS) |
|
Input Connection Type |
IEC 60320 C13 |
|
output connection type |
6 IEC 60320 C13 |
|
Battery type |
Lead-acid battery |
|
Number of battery filled slots |
0 |
|
Number of battery free slots |
0 |
|
Battery recharge time |
12 h |
|
Number of battery replacement quantity |
1 |
|
Battery voltage |
12 V |
|
Battery capacity |
7.0 Ah |
|
Battery charger power |
6 W rated |
|
Battery power in VAH |
75 VAh runtime |
|
Battery life |
3…5 year(s) |
|
Extended runtime |
0 |
|
Provided equipment |
User manual USB cable |
|
Number of power module free slots |
0 |
|
Number of power module filled slots |
0 |
|
Redundant |
No |
|
height |
19 cm |
|
Width |
9.1 cm |
|
Depth |
31 cm |
|
Net weight |
6.4 kg |
|
Mounting preference |
No preference |
|
Mounting mode |
Not rack-mountable |
|
Two post mountable |
0 |
|
USB compatible |
No |
|
Network frequency |
50/60 Hz +/- 3 Hz auto-sensing |
|
Input voltage limits |
176...294 V |
|
Maximum input current |
10 A |
|
Switching current capacity |
10 A |
|
Maximum configurable power in W |
390 W |
|
Output frequency |
50/60 Hz +/- 1 Hz sync to mains |
|
UPS type |
Line interactive |
|
Wave type |
Stepped approximation to a sinewave |
|
Maximum configurable power in VA |
650 VA |
|
Transfer time |
10 ms typical : 12 ms maximum |
|
product certifications |
A-Tick C-Tick CE EAC RCM TISI |
|
Marking |
GS Mark |
|
Standards |
EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
|
Ambient air temperature for operation |
0…40 °C |
|
Relative humidity |
0…95 % |
|
Operating altitude |
0...10000 ft |
|
Ambient air temperature for storage |
-15…45 °C |
|
Storage Relative Humidity |
0…95 % |
|
Storage altitude |
0.00…15240.00 m |
|
Acoustic level |
45 dBA |
|
Heat dissipation |
13.3 Btu/h |
|
control panel |
Multifunction LCD status and control console |
|
Alarm |
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
|
Noise suppression |
Full time multi-pole noise filtering : 10% of IEEE surge let-through : zero clamping response time: instantaneous |
|
Unit Type of Package 1 |
PCE |
|
Number of Units in Package 1 |
1 |
|
Package 1 Height |
25.5 cm |
|
Package 1 Width |
14.3 cm |
|
Package 1 Length |
44 cm |
|
Package 1 Weight |
7.4 kg |
|
SCC14 |
10731304346934 |
|
Warranty |
3 years repair or replace |
