APC BX2200MI-MS UPS Product Datasheet
|
Product Description |
APC Back-UPS BX2200MI-MS UPS ขนาด 2200VA/1200W, 230V, 4 Universal outlets, AVR ประกัน 3 Yrs. |
|---|---|
|
Main Input Voltage |
230 V |
|
Rated power in W |
1200 W |
|
Rated power in VA |
2200 VA |
|
output connection type |
4 universal |
|
Cable length |
1.22 m |
|
Number of cables |
1 |
|
Battery type |
Lead-acid battery |
|
Number of battery filled slots |
0 |
|
Number of battery free slots |
0 |
|
Battery recharge time |
8 h |
|
Battery voltage |
24 V |
|
Battery life |
3…5 year(s) |
|
Battery graph comments |
Curve fit to measured runtime data. All measurements taken with new, fully charged batteries, at typical environmental conditions, with no electrical input and balanced resistive load (PF = 1.0) output. |
|
Extended runtime |
0 |
|
Provided equipment |
User manual |
|
Max runtime |
240 min |
|
Number of power module free slots |
0 |
|
Number of power module filled slots |
0 |
|
Redundant |
No |
|
Colour |
Black |
|
height |
19 cm |
|
Width |
14 cm |
|
Depth |
39 cm |
|
Net weight |
12.3 kg |
|
Mounting preference |
No preference |
|
Mounting mode |
Not rack-mountable |
|
Two post mountable |
0 |
|
USB compatible |
No |
|
Network frequency |
50/60 Hz +/- 5 Hz auto-sensing |
|
Input voltage limits |
140...300 V |
|
Input Power Factor at Full Load |
0.54 |
|
Maximum configurable power in W |
1200 W |
|
Output frequency |
50/60 Hz +/- 1 Hz sync to mains |
|
UPS type |
Line interactive |
|
Wave type |
Stepped approximation to a sinewave |
|
Full load runtime |
00:01:00 1200 W |
|
Half load runtime |
00:08:30 600 W |
|
Maximum configurable power in VA |
2200 VA |
|
Transfer time |
6 ms typical : 10 ms maximum |
|
product certifications |
CE |
|
Standards |
EN/IEC 62040-1:2019/A11:2021 |
|
Equipment protection policy |
Lifetime : 50000 euros |
|
Ambient air temperature for operation |
0…40 °C |
|
Relative humidity |
0…95 % non-condensing |
|
Operating altitude |
0...3000 m |
|
Ambient air temperature for storage |
-15…40 °C |
|
Storage Relative Humidity |
0…95 % non-condensing |
|
Storage altitude |
0…3000 m |
|
Acoustic level |
40 dBA |
|
IP degree of protection |
IP20 |
|
control panel |
LED Status display with on line : on battery |
|
Surge energy rate |
273 J |
|
Unit Type of Package 1 |
PCE |
|
Number of Units in Package 1 |
1 |
|
Package 1 Height |
29.7 cm |
|
Package 1 Width |
49.5 cm |
|
Package 1 Length |
23.5 cm |
|
Package 1 Weight |
13.3 kg |
|
SCC14 |
10731304410734 |
|
Warranty |
3 years repair or replace |
