Dual-Band Wi-Fi 6 with seamless 802.11k/v/r roaming
HD Voice and Smart Noise Filtering
Wireless headsets connection via Bluetooth 5.0
2.4-inch 240 x 320 TFT color screen
4 SIP accounts,5-way conference
Product Specification
Overview
Yealink AX83H IP-Phone Wi-Fi Handset, WIFI6 Dual-Band รองรับ Roaming 11k/v/r, หน้าจอสี 2.4" TFT Color Screen, HD Voice, รองรับ 4 Account, Bluetooth 5.0
Specifications
Audio Features
Optimal HD audio: HD handset, HD speaker Hearing aid compatible (HAC) compliant Audio codec: G.722, PCMU (G.711μ), PCMA (G.711A), G.729, G.729A, G.729B, G.729AB, G.726, G.723.1, iLBC DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO Full-duplex hands-free speakerphone with AEC Smart Noise Cancellation Technology VAD, CNG, AEC, PLC, AJB, AGC
Display and Indicator
2.4" 240x320 TFT color screen Keypad backlight Vibration Wallpaper and screensaver LED for call and message waiting indication Multilingual user interface Caller ID with name, number, and avatar
Phone Features
4 VoIP accounts Speed dial, redial Call hold/call transfer/call waiting/call forward Emergency call Mute, DND Auto answer Hotline Recall Local 5-way conferencing Direct IP call without SIP proxy Ring tone selection/import/delete Set date time manually or automatically Dial Plan, XML Browser, Action URL/URI RTCP-XR (RFC3611), VQ-RTCPXR(RFC6035) Customizable softkey
2 soft keys 6 function keys: dial, hang up, handsfree, voice message, mute, call transfer Navigation key and OK key
Interface
1 x 3.5 mm headset jack 1 x Type-C port
Network
Built-in dual-band Wi-Fi: Network standard: 2.4G&5G, IEEE802.11a/b/g/n/ac/ax Frequency range: 2.4 GHz/ 5.0 GHz Roaming: IEEE802.11 k/r/v Built-in Bluetooth 5.0: Connecting to Bluetooth Headset IPv4/IPv6 SIP v1 (RFC2543), v2 (RFC3261) Call server redundancy supported NAT traversal: STUN mode SIP link mode: Proxy mode and peer-to-peer IP Assignment: static/DHCP HTTP/HTTPS web server Time and date synchronization using SNTP UDP/TCP/DNS-SRV (RFC 3263) QoS: Layer 3 ToS DSCP, 802.11e/WMM
Security
SRTP for voice TLS1.3 support HTTPS certificate manager AES encryption for configuration file (AES256) Digest authentication using MD5/MD5-sess OpenVPN, IEEE802.1X WPA, WPA2, WPA3 Secure boot GARP (Generic Attribute Registration Protocol)
Power
Power adapter: AC 100~240V input and DC 5V/1.2A output
Environmental
Factors
Operating humidity: 10%-95% Operating temperature: 0 to 40°C (+32 to 104°F) Storage temperature: -30 to 70℃
Package Features
Handset size: 151.0 x 49.5 x 21 mm Handset weight: 126 g Giftbox size: 181 × 104 × 90 mm Carton meas: 464 × 434 × 198 mm Qty/CTN: 20 PCS G.W/CTN: 8.03 kg N.W/CTN: 7.36 kg
