Product Specification |
Overview | Granstream GXP-1620 อุปกรณ์โทรศัพท์แบบ IP (IP-Phone) รองรับ 2 คู่สาย (2 SIP Account) ระบบเสียง HD-Audio หน้าจอสี LCD 180 x 60 Pixel รองรับการประชุม 3 คู่สาย รองรับ POE มาตรฐาน 802.3af |
Protocols/ Standards | SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP |
Networking Interfaces | Dual switched auto-sensing 10/100 Mbps Ethernet ports |
Graphical Display | 132 x 48 backlit graphical LCD display |
Feature Keys | 2 line keys with dual-color LED and 2 SIP accounts, 3 XML programmable context sensitive soft keys, 5 (navigation, menu) keys. 13 dedicated function keys for MUTE, HEADSET, TRANSFER, CONFERENCE, SEND and REDIAL, SPEAKERPHONE, VOLUME, PHONEBOOK, MESSAGE, HOLD, PAGE/ INTERCOM, RECORD, HOME |
Voice Codecs | Support for G.711?/a, G.722 (wide-band), G.723 (pending), G.726-32, G.729 A/B, in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC |
Telephony Features | Hold, transfer, forward, 3-way conference, call park, pickup, shared-call-appearance (SCA) / bridged-line-appearance (BLA), downloadable phone book (XML, LDAP, up to 2,000 items), call waiting, call log(up to 2,000 records), XML customization of screen, off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot desking, personalized music ringtones and music on hold, server redundancy and fail-over |
HD Audio | Yes, HD handset and speakerphone with support for wideband audio |
Headset Jack | RJ9 and 2.5mm headset jack |
Base Stand | Yes, 2 angled positions available, wall mountable |
Wall Mountable | Yes |
QoS | Layer 2 (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS |
Security | User and administrator level passwords, MD5 and MD5-sess based authentication, AES based secure configuration file, SRTP, TLS, 802.1x media access control |
Multi-language | English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, simplified and traditional Chinese, Korean, Japanese, etc |
Upgrade/ Provisioning | Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or encrypted XML configuration file |
Power | Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA |
Physical | Dimension: 209mm (L) x 184.5mm (W) x 76.2mm (H) (with handset)
Unit weight: 0.73kg; Package weight: 1.1kg |
Temperature and Humidity | Operation: 0?C to 40?C, Storage: -10?C to 60?C
Humidity: 10 to 90% Non-condensing |
Package Content | GXP1620/1625 phone, handset with cord, base stand, universal power supply, network cable, Quick Installation Guide, brochure, GPL License |
Compliance | FCC: Part 15 (CFR 47) Class B
CE : EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1
RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950; AS/NZS 60950.1 |
รับประกัน | Limited Life Time |
|
