EnGenius EWS320AP Neutron Series Access Point แบบ Dualband 2.4/5GHz ความเร็ว 450 Mbps
  • EnGenius EWS320AP Neutron Series Access Point แบบ Dualband 2.4/5GHz ความเร็ว 450 Mbps
  • EnGenius EWS320AP Neutron Series Access Point แบบ Dualband 2.4/5GHz ความเร็ว 450 Mbps
  • EnGenius EWS320AP Neutron Series Access Point แบบ Dualband 2.4/5GHz ความเร็ว 450 Mbps

EnGenius EWS320AP Neutron Series Access Point แบบ Dualband 2.4/5GHz ความเร็ว 450 Mbps

EnGenius EWS320AP Access Point Dual Band 2.4GHz/5GHz ความเร็ว 450 Mbps รองรับการควบคุมผ่าน Neutron Engenius Switch สำหรับสำนักงานที่ต้องการติดตั้งอุปกรณ์ AP ที่ต้องการประสิทธิภาพสูงสุด

฿0.00
ยังไม่ได้รวมภาษี
จำนวน
Out-of-Stock

รายละเอียด

การ Config อุปกรณ์ Engenius Neutron Series Controller

EWS320AP Datasheet
EWS320AP Quick Install Guide
EWS320AP User Manual

ลองทดสอบ Engenius Neutron Series Product

Engenius EWS320AP

Wireless Access Point อุปกรณ์สื่อสารด้วยระบบไร้สาย กระจายสัญญาณ Wireless 2 ย่านความถี่ (Dual-Band) 2.4GHz และ 5GHz พร้อมกัน ความเร็วสูง 450Mbps มาตรฐาน IEEE802.11a/b/g/n



เทคโนโลยี EnGenius Neutron Series Wireless Management solution รองรับการควบคุมการทำงาน หรือ Monitor ผ่านอุปกรณ์ Engenius Switch



เหมาะสำหรับอาคารสำนักงานที่ต้องการอุปกรณ์เชื่อมเครือข่ายแบบไร้สายที่มีความสวยงาม, กำลังส่งสูง และ ความเร็วสูงสุด หลีกเลี่ยงความแออัดของย่านความถี่ 2.4GHz



รองรับ Software การบริหารเครือข่าย WirelessEZ Controller Access Point Management software

Memory

Flash Memory 8Mb, SDRam 64Mb รองรับเครื่องลูกข่ายได้สูงมากไม่ต่ำกว่า 30 เครื่อง



รองรับการจ่ายไฟฟ้าผ่านไปกับสายแลน (Power Over Ethernet - IEEE 802.3af)

Mode การทำงาน

Access Point, Mesh AP(ยังอยู่ในขั้นตอนการพัฒนา Firmware)

LAN Port

1 Port Gigabit 10/100/1000 Mbps

SSID-TO-VLAN TAGGING

รองรับ 16SSID (8 SSID ต่อย่านความถี่) มาตรฐาน 802.1q VLAN tagging

Modulations

OFDM: BPSK, QPSK, 26-OAM, 64-QAM, DBPSK, DQPSK, CCK

Wireless Security

WPA/WPA2 Personal (WPA-PSK using TKIP or AES)
WPA/WPA2 Enterprise (WPA-EAP using TKIP)
802.1X RADIUS Authenticator: MD5/TLS/TTLS, PEAP
SSID broadcast enable/disable
MAC Address Filtering, Up to 50 field
L2 Isolation (Access Point mode)
Wireless STA (Client) connected list (Idle/Connection Time, Pkt statistics)

การใช้งานร่วมกับ Neutron Series Switch

• Access Point Auto Discovery and Provisioning
• Access Point Auto IP Assignment
• Access Point Cluster Management
• Remote Access Point Rebooting
• Access Point Device Name Editing
• Access Point Radio Settings
• Band Steering
• Traffic Shaping
• Fast Handover
• Seamless Roaming (requires RADIUS server)
• Access Point Client Limiting
• Mesh Network*
• Wireless Security (WEP, WPA/WPA2 Enterprise, WPA/WPA2 PSK)
• VLANs for Access Point- Multiple SSIDs
• Guest Network
• Access Point Status Monitoring
• Wireless Client Monitoring
• Wireless Traffic & Usage Statistics
• Visual Topology View
• Floor Plan View
• Map View
• Secure Control Messaging
• SSL Certificate
• Local MAC Address Database
• Remote MAC Address Database (RADIUS)
• Unified Configuration Import / Export
• Bulk Firmware Upgrade Capability
• Intelligent Diagnostics

* Mesh networking mode available soon as a free firmware upgrade

Management

Adjust transmit power by dBm
Web-based configuration (http)/Telnet
Reboot (press 1 second).
Reset to factory default (press 10 seconds)
Status Statistic and Event Log
SNMP: V1, V2c, V3
Auto Reboot Access Point by minute, hour, day, or week
Incoming and outgoing wireless traffic shaping
Supports Command Line Interface
Scanning for available EnGenius Aps

เสาอากาศ

3 dBi X 3 ต้น (ย่านความถี่ 2.4 GHz)
3 dBi X 3 ต้น (ย่านความถี่ 5 GHz)
ไม่สามารถเพิ่มเติมเสาอากาศภายนอกได

Dimension

-

Weight

-

Power

12V/2A รองรับการจ่ายไฟผ่าน POE มาตรฐาน 802.3at (อุปกรณ์เสริม)

Temperature Range

0 to 50? C - Operating, -20 to 60 ? C - Storage

Warranty

2 ปี, Adapter 3 เดือน



*** การปรับกำลังส่งของอุปกรณ์ ต้องเป็นไปตามที่กฏหมายกำหนดไว้

รายละเอียดสินค้า
0

ข้อมูลสินค้า

ลักษณะงาน Wireless
กระจายสัญญาณ WIFI
ความเร็ว มาตรฐาน WIFI
WIFI-4 (n) 300Mbps
ย่านความถี่
Dual-Band 2.4/5GHz
รองรับ POE
Yes
High-Power
กำลังส่งสูง
