ACTi Bullet D42A 3MP IR Day/Night IP Bullet Camera, 2-Way Audio Support, 2.8-12mm Varifocal Lens
|
Image Sensor | 1/3.2" progressive scan CMOS |
Minimum Illumination | Color: 0.1 lux at f/1.6 (30 IRE, 2,400 K)
B/W: 0 lux (IR LED on) |
Color to B/W switch | ISP-based switch, configurable |
IR Sensitivity Range | 700 to 1,100 nm |
IR LED | IR LED x 15 (850 nm) |
IR Working Distance | 49.21' (15.00 m), 0 lux, 30 IRE at maximum exposure gain |
Electronic Shutter | 1/5 to 1/10,000 sec (auto mode), 1/5 to 1/2,000 sec (manual mode) |
|
Focal Length / Aperture | Varifocal, f3.3 to 12 mm /F1.6 |
Iris | Fixed |
Focus | Manual |
Mount Type | Board |
Horizontal Viewing Angle | 78.0 to 22.0˚ |
|
Compression | H.264 high profile, MJPEG |
Maximum Frame Rate vs. Resolution | 15 fps at 2592 x 1944; 15 fps at 2048 x 1536; 30 fps at 1920 x 1080; 30 fps at 1280 x 720; 30 fps at 640 x 480 |
Multi-Streaming | Simultaneous dual streams based on 2 configurations |
Bit Rate | 28 kb/s to 6 Mb/s (per stream) |
Bit Rate Mode | Constant, variable |
Image Enhancement | Basic WDR
White Balance: Automatic, hold, and manual
Brightness
Contrast
Auto Gain Control
Digital Noise Reduction
Flickerless |
Privacy Mask Type | 4 configurable regions |
Text Overlay | User-defined text on video |
Graphics | On-Screen: User defined image layer on video |
Image Orientation | Flip and mirror |
|
Protocol | TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour |
Ethernet Port | 1, Ethernet (10/100 Base-T), RJ-45 connector |
Security | IP address filtering; HTTPS encryption; password-protected user levels; IEEE 802.1X network access control |
|
Alarm Triggers | Video motion detection (3 regions) |
Alarm Response | Notify control center; change camera settings; command other devices; send email notifications with snapshots; upload videos or snapshots to FTP server |
|
Digital I/O | Terminal block |
Local Storage | microSDHC/SDXC memory card slot 1 |
|
Unified Solution | Fully compatible with ACTi software |
ISV Integration | SDK (Software Development Kit) available, ONVIF compliant |
Firmware Access Browser | Microsoft Internet Explorer 6.0 or newer (full functionality), Other browsers with VLC installed (partial functionality) |
|
Power Source | PoE Class 2 (IEEE802.3af) |
Power Consumption | 4.9 W (IR on) |
Environmental Casing | Weatherproof (IP66 rated) |
Mount Type | Wall, ceiling, corner, pole |
Operating Temperature | -4 to 122°F (-20 to 50°C) |
Operating Humidity | 10 to 85% RH |
Approvals | CE, FCC, IP66 |
Dimensions (Ø x L) | 3.03 x 8.39" (77.00 x 213.00 mm) |
Weight | 1.41 lb (639.00 g) |
