Overview
|
BDCom S2900-24T4X L3-lite Managed 24 Port Gigabit, 4 Port SFP+ 10 Gigabit
รองรับ VLAN, STP, IGMP Snooping, Static route/RIP/OSPF, LACP, VRRP, 802.1x, Dual Stack
|
Gigabit Interface
|
|
| RJ45 |
24 |
| SFP |
/ |
| 10G/GE Interface |
6 |
| Console（RJ45） |
1 |
| Backplane（Gbps） |
216 |
| Forwarding rate（Mpps） |
126 |
| Chassis Dimensions (WxDxH)(mm) |
440x350x44 |
| Package Dimensions (WxDxH)(mm) |
576x448x94 |
| Power supply (hot-swap) AC: 100V-240V, 50Hz±10% |
75W |
| Total output BTU (1000BTU/H=293W) |
255.97 |
| Noise@25°C（dBA) |
45 |
| MTBF(H) |
>200,000 |
| Forwarding mode |
Store-forward |
| Flash (MB) |
16 |
| DRAM (MB) |
512 |
| MAC |
32K |
| Buffer size(MB) |
2 |
| Jumbo frame |
9K |
| Routing table |
|
| IPv4 |
12K |
| IPv6 |
6K |
| ARP table |
|
| IPv4 |
12K |
| IPv6 |
2K |
| Total SVI |
1K |
Features
|
|
VLAN
|
4K Active VLAN, QinQ & Selective QinQ, GVRP, Voice VLAN
|
|
Spanning Tree
|
802.1D (STP), 802.1W (RSTP) and 802.1S (MSTP)
BPDU guard, root guard and loopback guard
|
|
Multicast
|
IGMP v1/v2/v3, IGMP Snooping, IGMP Fast Leave, MVR, IGMP filter
|
|
IPv4
|
Static routing, RIP v1/v2, OSPF,BGP, PBR, ECMP
BFD for OSPF, BGP
|
|
IPV6
|
ICMPv6, DHCPv6, ACLv6 and Ipv6 Telnet
IPv6 neighbor discovery,Path MTU discovery
MLD V1,MLD snooping IPv6 Static Routing,RIPng, OSPFv3
Manual tunnel,ISATAP tunnel,6 to 4 tunnel
|
|
Certification
|
CE, FCC, ROHS
|
|
QoS
|
CAR, HQoS, MAC/IP/TCP/UDP/VLAN/COS/DSCP/TOS based QoS, 802.1P/DSCP priority relabeling, SP, WRR, and “SP+WRR”, Tail-Drop, WRED, flow monitoring and traffic shaping
|
|
Security
|
Port isolation, Port security, and “IP+MAC+port” binding, MAC sticky
DHCP Snooping and option 82, DAI & IP source guard, PPPoE+, · IEEE 802.1x, Radius and BDTacacs+
L2/L3/L4 ACL flow identification and filtrationAnti-attack from DDoS, TCP’s SYN Flood, UDP Flood, etc. Broadcast/multicast/unknown unicast storm-control
MD5, SHA-256, RSA-1024, AES256, etc.
|
|
DHCP
|
DHCP server/relay/client
DHCP snooping/option82
|
| MPLS |
Multi-VRF
|
|
Reliability
|
Static/LACP link aggregation,Interface backup
BVSS virtual-stacking
EAPS and ERPS
URPF, LLDP
ISSU
VRRP
1+1 power backup
|
|
Management
|
Console, Telnet, SSH v1/2, HTTP,HTTPS,SNMP v1/v2/v3, RMON
TFTP, FTP, SFTP
NTP, SPAN, RSPAN
sFlow
|
|
Environment
|
Operating temperature/ humidity: 0℃ -50℃ ,10%-90% non-condensing
Storage temperature/humidity:-20℃ -70℃ , 5%-95% noncondensing
|
|
Accessories
|
Power cord,rackmount kits, console cable
|
|
รับประกัน
|
3 ปี
|
