Product Specification |
|
|
|
Overview |
Mikrotik Cloud Core Router รุ่น CCR1036-8G-2S+ อุปกรณ์ Router ระดับ Top สำหรับทำระบบ Firewall, Bandwidth Management, Web Proxy, Dynamic Routing Protocol (RIP, OSPF, BGP), Secure Tunnel (EoIP, PPPoE, PPTP, L2TP, OVPN 200 Connection), VLAN, P2P Firewall Rules, Nat Rules, Hotspot Gateway (Unlimit User), Radius Client, Unlimited Queues, User Manager (Unlimit Active Session), Synchronous Interface, Core Router |
|
ทำระบบ Hotspot Authenticate ได้ประมาณ 200-300 Users พร้อมกัน |
CPU |
TLR4-03680CG-12CE-A3b |
Memory |
Two SODIMM DDR3 slots, 4GB (2x2GB) installed (no hardware or software max limit) |
Data storage |
1 GB Onboard NAND |
Operating System |
RouterOS v6 (64bit) |
Hotspot Account |
รองรับได้ไม่จำกัดจำนวน Account (UnLimit) |
Ethernet |
8 Port 10/100/1000 Mbit/s Gigabit Ethernet with Auto-MDI/X |
miniPCI |
n/a |
Serial port |
1 Port RS232 (DB9) |
SFP Port |
n/a |
SFP+ Port |
2 Port (รองรับความเร็ว 10Gbps) |
Memory Cards |
1 MicroSD Slot |
802.3af Support |
Yes |
POE In |
No |
Voltage Monitor |
Yes |
PCB temperature monitor |
Yes |
CPU temperature monitor |
Yes |
Current Monitor |
Yes |
Power options |
IEC C14 standard connector 110/220V (PSU included), up to 60W power consumption |
Temperature |
Max ambient temperature 50? @ 1.2GHz; 70? @ 1GHz CPU core frequency |
Dimensions |
1U case: 355 x 145 x 55mm |
Weight |
1,200g |
Operating Temperature |
-20C ถึง +70C |
รับประกัน |
1 ปี |
