Product Specification | |
Fixed WAN Port | 1×10/100/1000 Base-T |
Fixed LAN Port(s) | 6×10/100/1000 Base-T |
LAN/WAN Switchable Port(s) | 3×10/100/1000 Base-T |
Performance | 1.5 Gbps (1518 Byte,NAT+Flow Audit) |
Throughput | 1.5 Gbps |
Recommended Clients | 300 |
Power Consumption | ≤ 15 W |
Network Access Mode | PPPoE Client |
Automatic Identification of Internet Type | Support |
Avoidance of WAN IP Address Conflicts | Support |
Learning PPPoE Account & Password | Support |
VLAN | 8 |
IPv6 | Support |
IPTV | Support |
AC Mode | Support |
Behavior Management | App Block (Time/IP-based Policy) |
Application Recognition | Identify 100+ Applications, including Office, IM, Web Page, Online Shopping, Online Gaming, P2P Download and Popular Videos |
Application Priority | Support |
Flow Control | Smart Flow Control |
Traffic Audit | Real-time Traffic Audit |
Diagnosis | Support |
Marketing authentication | WiFiDog (SMS authentication and one-click authentication) |
Local authentication | Portal Authentication |
Max Manager Reyee Switchs | 128 |
No. of PPPoE Server Account | 64 |
VPN Support | L2TP VPN |
No. of PPTP&L2TP&OpenVPN Account | 300 |
Overall IPsec VPN Performance | 230 Mbps |
Overall L2TP VPN Performance | 640 Mbps |
Overall OPENVPN Performance | 100 Mbps |
VPN Tunnels | IPsec : 64 |
Routing | Static, RIP/RIPng |
Policy-Based Routing (PBR) | Support |
WAN Port Failover | Support |
WAN Load Balancing | Support |
Load Balance Mode | Load balancing based on source address |
DDNS | Oray DDNS,DynDns, NO-IP, Ruijie DDNS |
Port Mapping | Support |
ACL/Time-based ACLs | Support |
ARP binding | Support |
Firewall | Prevent Port Scan Attack |
Management | Cloud, Mobite App |
CPU | 2 Cores, 1.35 GHz |
SDRAM/RAM | 512 MB |
Flash Memory | Flash Memory |
Power Supplies | 100V~240V AC, 50/ 60Hz |
PoE Standard | N/A |
PoE Power Budget | N/A |
Dimensions(W×D×H) | 43.6 mm x 440 mm x 200 mm |
Weight | 2.4 kg (packages not included) |
Installation | Rack-mounted |
Rack Dimensions | 1U 19-inch Rack-mounted |
Operating Temperature | 0°C to 40°C (32°F to 104°F) |
Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
Operating Humidity | 10% to 90% Noncondensing |
Storage Humidity | 5% to 90% Noncondensing |
Port Surge | 4 kV |
ประกัน | ประกันศูนย์ Ruijie Thailand 3 ปี |
รับติดตั้ง , Setup ระบบเชื่อมต่อเครือข่ายระหว่างสาขาด้วย VPN Site To Stite
รายละเอียดการทำ VPN https://sysnetcenter.com/news/post/how-to-network-vpn
ระบบจะทำการเชื่อมวง Network แต่ละสาขาเข้าด้วยกัน สามารถ Share File, Printer, Database, VOIP
Share File / Printer ระหว่างสาขา
โทรศัพท์ระหว่างสาขาหากันฟรีด้วย VOIP ผ่าน VPN
เชื่อมต่อฐานข้อมูลที่เป็น RDBMS เช่น MS SQL, Oracle, MySQL ได้ง่าย โดยการสร้าง Connection String ชี้ไปที่ Databse Server ได้เลย
Feature | Ruijie Enterprise | Reyee |
Ruijie Cloud | Support | Support |
Mobile App | Support | Support |
Review Ruijie Cloud ระบบ Managed & Monitor อุปกรณ์ Ruijie ผ่าน Cloud | ||
Presales Tools | Support | Support |
Fast Provisioning | Scan QR-code Device | Self-organizing network (SON) |
Monitoring & Alarm | Support | Support |
Device Management | Additional: | Basic |
Gateway Management | WAN Load Balance | WAN Load Balance |
Gateway Authen | Local Authen (Captive Portal) | Local Authen (Captive Portal) |
Review Ruijie RG-EG3230/RG-EG3250 Loadbalance Gateway | ||
Multi-tenant | Support | Support |
Scenario-based | N/A | Support (App) |
Wireless | ||
Standard | WIFI 4 (n) | WIFI 5 Wave2 (ac) |
Capacity | Max Client 1024 (Wi-Fi 6) | Max Client 128 |
WLAN Auth | 802.1x Auth | PSK/WPA2 |
Review Ruijie Cloud WIFI Authentication ระบบ Login เข้าใช้งาน Internet | ||
WLAN Features | L2/L3 Roaming | L2 Roaming |
WLAN Controller | Yes | Yes |
Switches | ||
Capacity | Chassis model option (upto 48 10GE) | Box Switches model (upto 24GE +10G uplink |
L2 | IGMP Snooping | VLAN |
L3 | IPv6, RIP, OSPF, PBR, VRRP | N/A< |
Security / Availability | 802.1x, CPP/NFPP, REUP, VSU | N/A |
Management | Managed with Web & CLI (Console port), SSH, SNMP | Web Smart Managed & Unmanaged |
