Ruijie RG-ES100 Series UnManaged Smart Switch Datasheet
Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide
Reyee RG-ES126S-P V2 Highlight Features
- Cloud visible even unmanaged switch
- Intelligent PoE management
- High-quality makes network reliable
- Better quality design
- Designed for various scenariosLarge buffer for smooth data transmission
Product Specification |
Overview | Reyee RG-ES126S-P V2 100Mbps POE Switch 26 Port ความเร็ว 10/100Mbps จ่ายไฟมาตรฐาน 802.3af/at 24 Port 370W, Uplink 2 Port Gigabit |
Downlink Ports | 24 x 10/100BASE-TX |
Uplink Ports | 2 x 10/100/1000BASE-T with 1 Combo port |
PoE/PoE+ ports | 24 |
Max. PoE budget | 370W |
Switching capacity | 8.8 Gbps |
Forwarding rate | 6.55 Mpps |
MAC address table | 16000 |
Dimensions (W x D x H) | 440 mm × 208 mm × 44 mm |
Weight (With package) | 3 kg |
Auto/Full/Half Duplex Negotiation | Support |
Auto MDI/MDIX | Support |
Cloud Management | Cloud monitoring |
Flow Control | Support |
Port Isolation | Support |
Power Consumption | <432W |
Power Supplies | 100V AC to 240V AC, 4A |
Surge Protection | 6kV |
Fan | Support |
Operating Temperature | 0°C to 45°C (32°F to 109°F) |
Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
Operating Humidity | 10% RH to 90% RH |
Storage Humidity | 5% RH to 95% RH |
MTBF | > 200,000 |
Certificate | CE, RoHS |
ประกัน | 3 ปี |
RG-ES126S-P
24-Port 10/100Mbps, 2-Port Gigabit Unmanaged Switch with 24 PoE+ Ports
Cloud Visible Even Unmanaged Switch*
* Unmanaged switch visible on cloud requires at least 1 managed switch in the same network.
Large Buffer for Smooth CCTV Transmission
Hardware flow control, guarantee the large buffer
Intelligent PoE Management
Fit for various powered devices, single port up to 30W
High-quality Makes Network Reliable
Stable without frequent reboot
Better quality design
Strict standards in PCB design and component selection
Designed for Various Scenarios
รายละเอียดสินค้า
20 รายการ
ข้อมูลสินค้า
- Switches Layer
- UnManaged
- จำนวน Port Lan
- 24 Port
- ความเร็ว Port Lan
- 100Mbps
- จำนวน Port จ่ายไฟ POE
- 24 Port
- มาตรฐานจ่ายไฟ POE
- POE+ 802.3at (30W)
- มี Uplink Port Lan Gigabit
- Yes
