แบรนด์: Ruijie Networks
RG-ES210GC-LP
Reyee Cloud Managed Smart Switch for IP surveillance 10 Port Gigabit, จ่ายไฟ POE 8 Port 802.3af/at 70W, Uplink 2 Port รองรับ VLAN, Remote POE Reboot, Loop Detection, Managed ผ่าน Ruijie Cloud Controller
ตัวแทนจำหน่าย Ruijie/Reyee อย่างเป็นทางการ
ทีมงาน Certificate Support
ต้องการรายละเอียดสินค้าเพิ่มเติม LINE: @sysnet
Review Ruijie RG-ES200 Series Cloud Managed POE Switch สำหรับงาน CCTV, WIFI
Review Ruijie Reyee POE Switch รองรับ Managed ผ่าน Ruijie Cloud
Review Ruijie Cloud ระบบ Managed & Monitor อุปกรณ์ Ruijie ผ่าน Cloud ฟรี
Reyee Series Implementation Cookbook V1.0
RG-ES200 Series Web-Based Configuration Guide
Ruijie RG-ES200 Series Switches Hardware Installation and Reference Guide
RG-ES210GC-LP Quick Installation Guide
RG-ES200 Series Datasheet
L2 Managed Gigabit POE Switch 10 Port ความเร็ว Gigabit สามารถจ่ายไฟ POE มาตรฐาน 802.3af/at (15.4W/30W) ได้ 8 Port รวมกำลังไฟสูงสุด 70W เฉลี่ยต่อ Port 8.7W
ไม่แนะนำใช้กับ Access Point ที่เป็น WIFI 6 ประเภท 4x4 หรือกล้องพวก Speed dome ครับ พวกนี้ใช้กำลังไฟสูงมาก แนะนำใช้ร่วมกับกล้อง IP Camera ที่เป็นแบบ Fix เพราะอุปกรณ์พวกนี้ใช้ไฟน้อยประมาณ 5-6W หรือให้ทางร้านคำนวนให้ได้เลยครับ
และถ้าใช้กับ Access Point ที่เป็น WIFI 6 ถ้าติดตั้งหลายๆตัว ค่า Forwarding Rate อาจจะไม่พอ แนะนำเป็น Reyee Series NBS3100 ขึ้นไปจะดีกว่าครับ
รุ่นนี้ Port Uplink เป็น Port LAN RJ45 x 2Port Gigabit ถ้าใช้ร่วมกับกล้อง IP Camera ก็จะใช้ Port ต่อเข้า NVR และ ต่อเข้า Router ได้เลย
Product Specification |
|
Ports |
8 10/100/1000 Base-T ports (PoE/PoE+) |
Maximum output power per PoE port |
30W |
Maximum PoE output power per switch |
กำลังไฟสูงสุด 70W |
Switching capacity |
20Gbps |
Switching Cache |
1.5Mbit |
Packet forwarding rate |
14.8Mpps |
Surge protection |
Common mode: 4KV |
Electrostatic discharge |
Air discharge: 6KV |
Power consumption |
≤80W |
Power supply |
External power adapter 100-240V |
Dimensions (W x D x H) |
202 x 108 x 28mm |
MTBF |
>200K |
Operating temperature |
0 to 40°C |
Storage temperature |
-40~70ºC |
Operating humidity |
10% to 90% RH |
Storage humidity |
5% to 95% RH |
MAC capacity |
4K |
Static MAC address |
16 |
VLAN |
Support 802.1Q VLAN |
Port management |
Support port status display, port traffic statistics, PoE port output power status, port duplex / negotiation rate configuration, flow control configuration, PoE output on/off |
Security |
Support broadcast storm suppression, port speed limit, port isolation |
L2 features |
Support port mirroring, loop protection, cable detection |
Management |
Support management and configuration through web management interface, Ruijie Cloud platform and Ruijie Cloud app |
ประกัน |
ทางร้านเป็นตัวแทนจำหน่ายอย่างเป็นทางการ ประกันศูนย์ Ruijie Thailand 3 ปี |
