Port Lan Multi-Gigabit 1/2.5Gbps สำหรับ Access Point Wi-Fi 6/7 APs
Ruijie Cloud License ฟรี ตลอดชีพ
802.3at/af-compliant PoE+ ports with a total power supply of 240 W
รองรับ VLAN 802.1q ได้สูงสุด 4094VLAN
รองรับการทำ Static Link Aggregate กรณีต้องการรวมความเร็วสาย Lan มากกว่า 1 เส้น
รองรับการทำ IGMP Snooping
รองรับ DHCP Snooping ป้องกันพวก DHCP Server ที่ไม่เกี่ยวข้องเชื่อมต่อเข้ามา
รองรับ Remote Rebbot POE
รองรับ Real-Time Alarm
Product Specification
Hardware Specifications
Number of 10/100/1000/2500Base-T Ports
8
Number of 10 Gbps Optical Ports (SFP+)
2
Number of PoE/PoE+ Ports
8
Number of PoE/PoE+/PoE++ Ports
N/A
Number of Fans
2
Power Supply Options
Single fixed power supply
Forwarding Rate
58.72Mpps
Switching Capacity
80Gbps
MAC Address Table Size
16000
ARP Table Size
1000
Number of ACEs
In-1900 Out-0
Dimensions (W x D x H)
300mm x 233mm x 43.6mm
Power Supply
Rated voltage range: 100-240V~ Maximum voltage range: 90-264V~ Frequency: 50/60Hz Rated current: 6A
Power Consumption
No PoE load: <27W Full PoE load: <278W
Max. PoE Power Budget
240W
Output Power
Vout=54V(5.4A), P=290W
Operating Temperature
0 to 50°C
Storage Temperature
-40 to 70ºC
Operating Humidity
10% to 90% RH(non-condensing)
Port Surge Protection
Common Mode 6 kV
Power Supply Surge Protection
Common Mode 6kV Differential Mode 6kV
Net Weight
2.64kg
Gross Weight
3.45kg(packages included)
Certification
CE; FCC
Software Specifications
Jumbo Frame
9216 Bytes(Global MTU)
VLAN
802.1Q VLAN Port-based VLAN Voice VLAN
STP
STP (IEEE 802.1d) RSTP (IEEE 802.1w)
LLDP
LLDP LLDP-MED
DHCP
DHCP Snooping DHCP Client
IGMP
IGMP Snooping(Internet Group Management Protocol Snooping) IGMP Snooping v1 IGMP Snooping v2 IGMP Snooping v3(Basic) MVR mode (The user port can only be configured as an access port.) IGMP Filtering IGMP Fast Leave
ACL
IP Standard ACL MAC Extended ACL IP Extended ACL IPv6 ACL
QoS
Port-Level Rate Limiting (Ingress/Egress)
802.1X
IEEE 802.1X Authentication Port-based Authentication MAC-based Authentication Global IEEE 802.1X Authentication Control Port Mandatory Authentication Port Optional Authentication Port-based Single-host Mode Supports PEAP Authentication Modes for Windows 7/8/10/11 Clients Supports PEAP Authentication Modes for macOS Clients Supports PEAP Authentication Modes for Linux OS Clients
Web Management
Web Authentication HTTP HTTPS
Security
IP+MAC Port Binding Anti-ARP Spoofing IP Source Guard CPU Protection Policy (CPP)
