| IPC322CR3-VSPF28-A | IPC322CR3-VSPF40-A |
| Camera |
| Sensor | 1/2.7", progressive scan, 2.0 megapixel, CMOS |
| Lens | [email protected] | [email protected] |
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
| 2.8 | 46.7 | 18.7 | 9.3 | 4.7 |
| 4.0 | 66.7 | 26.7 | 13.3 | 6.7 |
| Angle of View (H) | 112.7° | 86.5° |
| Angle of View (V) | 60.1° | 44.1° |
| Angle of View (O) | 146.5° | 106.4° |
| Adjustment angle | Pan: 0° ~ 360° | Tilt: 0° ~ 75° |
| Shutter | Auto/Manual, 1 ~ 1/100000s |
| Minimum Illumination | Colour: 0.02Lux ( F2.0, AGC ON) 0Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital noise reduction | 2D/3D DNR |
| S/N | >52dB |
| IR Range | Up to 30m (98ft) IR range |
| WDR | DWDR |
| Video |
| Video Compression | Ultra 265, H.265, H.264 |
| H.264 code profile | Baseline profile, Main Profile |
| Frame Rate | Main Stream: 1080P (1920*1080), Max 25fps; Sub Stream: 4CIF (704*576), Max 25fps; Third Stream: CIF (352*288), Max 25fps |
| HLC | Supported |
| BLC | Supported |
| OSD | Up to 4 OSDs |
| Privacy Mask | Up to 4 areas |
| ROI | Up to 2 areas |
| Motion Detection | Up to 4 areas |
| Network |
| Protocols | IPv4, IGMP, ICMP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, UPnP, HTTP |
| Compatible Integration | ONVIF (Profile S, Profile T), API |
| Interface |
| Network | 10/100M Base-TX Ethernet |
| General |
| Power | DC 12V±25%, PoE (IEEE 802.3af) |
| Power consumption: Max 4.0W |
| Dimensions (Ø x H) | Φ109 x 81mm (Ø4.3” x 3.2”) |
| Weight | 0.37kg (0.81lb) |
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Ingress Protection | IP67 |
| Vandal Resistant | IK10 |
