    GS1300-10HP Zyxel Unmanaged Gigabit POE Switch 8 Port POE 802.3at 130W
    • GS1300-10HP Zyxel Unmanaged Gigabit POE Switch 8 Port POE 802.3at 130W
    • GS1300-10HP Zyxel Unmanaged Gigabit POE Switch 8 Port POE 802.3at 130W
    • GS1300-10HP Zyxel Unmanaged Gigabit POE Switch 8 Port POE 802.3at 130W
    • GS1300-10HP Zyxel Unmanaged Gigabit POE Switch 8 Port POE 802.3at 130W

    GS1300-10HP Zyxel Unmanaged Gigabit POE Switch 8 Port POE 802.3at 130W

    ZyXel

    GS1300-10HP

    Zyxel GS1300-10HP Unmanaged Gigabit POE Switch 8 Port ความเร็ว Gigabit จ่ายไฟ POE มาตรฐาน 802.3at 8 Port กำลังไฟสูงสุด 130W, Extended Range Mode

    ฿7,590.00
    ยังไม่ได้รวมภาษี
    จำนวน
    12 รายการ


    สอบถามข้อมูลสินค้าเพิ่มเติม

    LINE ID: @sysnet  โทร: 02 102 4284

    Click ต้องการใบเสนอราคา

    close

    แบบฟอร์มขอใบเสนอราคา



    Rating:
    (0)
    รายละเอียด

    Zyxel GS-1300-10HP Datasheet

    Mode Extended Range รองรับสาย Lan ยาว 200 เมตร Switch Zyxel GS1300 Series



    Zyxel GS1300-10HP Unmanaged Gigabit POE Switch

    Overview

    Zyxel GS1300-10HP Unmanaged Gigabit POE Switch 8 Port ความเร็ว Gigabit , 1 Port SFP
    จ่ายไฟ POE มาตรฐาน 802.3af/at ได้ 8 Port กำลังไฟสูงสุด 130W

    Mode Extended Range ใช้ร่วมกับสาย Lan ความยาวได้สูงถึง 250 เมตร

    Zyxel ARS (Advance Replacement Service) ฟรี 1 ปี

    ลงทะเบียนสินค้าที่ http://ars.zyxel.co.th
    ระบบเครือข่ายไม่หยุดชะงัก
    ไม่เสียโอกาสทางธุรกิจ
    สำรองข้อมูลการตั้งค่าได้
    จัดส่งสินค้าทดแทนถึงที่
    ไม่มีค่าใช้จ่าย

    Total port count

    10

    100/1000 Mbps

    9

    Gigabit SFP

    1

    Configurable extended range ports

    2

    PoE ports

    8

    Total PoE budget (watt)

    130

    PoE 802.3at

    Yes

    Switching capacity (Gbps)

    20

    Forwarding rate (Mpps)

    14.8

    Packet buffer (byte)

    525 K

    MAC address table

    8 K

    Input

    100 - 240 V AC, 50/60 Hz

    Max. power consumption (watt)

    155.8

    Dimensions (WxDxH)(mm/in.)

    267 x 162 x 44 /
    10.51 x 6.38 x 1.73

    Weight (kg/lb.)

    1.65/3.64

    Included accessories

    Power cord
    Wall-mount kit
    Rack mounting kit

    Operating

    Temperature -20?C to 50?C/-4?F to 122?F
    Humidity 5% to 95% (non-condensing)

    Storage

    Temperature -40?C to 70?C/-40?F to 158?F
    Humidity 5% to 95% (non-condensing)

    MTBF (hr)

    394,567

    Heat dissipation (BTU/hr)

    531.278

    Acoustic noise @ 25?C (dBA)

    44



    Design For Surveillance

    Crafted for CCTV, Zyxel introduces the brand-new GS1300 unmanaged switch for surveillance applications.

    Design For Surveillance

    New outlook

    Coated in titanium grey, the GS1300 excels with an eye-catching identity dedicated for surveillance Switch. On top of the conventional unmanaged switch, GS1300 comes with special design for CCTV adoption.

    New outlook



    Easy for long-distance deployment

    The GS1300 series overcomes the 100 meter limitation of Ethernet, and fulfills the need to deploy IP camera or powered devices using existing Cat 5e cable to distant locations. By toggling the DIP switch to turn on the extended-range mode, instantly achieve distant deployments up to 250 meters. Save your money and effort with simply one PoE Switch.



    Easy for long-distance deployment

    รายละเอียดสินค้า
    12 รายการ

    ข้อมูลสินค้า

    Switches Layer
    UnManaged
    จำนวน Port Lan
    8 Port
    ความเร็ว Port Lan
    1Gbps (Gigabit)
    จำนวน Port POE
    8 Port
    มาตรฐานจ่ายไฟ POE
    POE+ 802.3at (30W)
    มี Uplink Port Lan Gigabit
    Yes
    จำนวน SFP Port 1Gigabit
    1 Port
    รองรับสาย Lan 250 เมตร
    Yes
