Resolution
|
3 MP
|
|
Image Sensor
|
1/3.2" Progressive scan CMOS
|
|
Minimum Illumination
|
Color: 0.1 lux at f/2.0 (30 IRE, 2400 K)
|
|
Lens
|
2.8 mm, f/2.0 fixed
|
|
Mount
|
CS mount (interchangeable lens)
|
|
Iris
|
Fixed
|
|
Focus
|
Manual
|
|
Electronic Shutter
|
Manual: 1/5 to 1/2,000 sec
Auto: 1/5 to 1/10,000 sec
|
|
Horizontal Viewing Angle
|
92.6°
|
|
Compression
|
H.264, HP, and MJPEG
|
|
Maximum Frame Rate
|
15 fps at 2048 x 1536, 320 x 240; 30 fps at 1920 x 1080, 1280 x 720, 640 x 480
|
|
Multi-Streaming
|
Dual streams
|
|
Bit Rate
|
28 Kb/s to 6 Mb/s (per stream)
|
|
Bit Rate Mode
|
Constant, variable
|
|
Wide Dynamic Range
|
Basic WDR (74 dB)
|
|
Digital Noise Reduction (DNR)
|
Yes
|
|
White Balance
|
Automatic, hold, and manual
|
|
Image Enhancement
|
Brightness, contrast, sharpness(auto); flickerless
|
|
Privacy Masking
|
4 configurable regions
|
|
Text Overlay
|
User defined text on video
|
|
Image Orientation
|
Image flip and mirror
|
|
Audio Compression
|
8 kHz, mono, PCM, 16 bit encoding; G.711
|
|
Audio In
|
Built-in microphone
|
|
Audio Out
|
3.5mm phone jack
|
|
Protocol
|
TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour
|
|
Ethernet Port
|
1 x 10/100 Base-T, 1 x RJ-45
|
|
Security
|
IP address filtering; HTTPs encryption, password protected user levels, anonymous login, IEEE802.1X network access control
|
|
Alarm Trigger
|
Video motion detection (3 regions)
|
|
Alarm Response
|
Notify control center, change camera settings, command other devices; email notification with snapshots, upload video, snapshot to FTP server
|
|
Power Source
|
PoE class 2 (IEEE802.3af) / 3.67 W
|
|
Bundled Accessories
|
Bracket
|
|
Mount Type
|
Wall, ceiling
|
|
Unified Solution
|
Compatible with ACTi software
|
|
ISV Integration
|
Software Development Kit (SDK) available on request
|
|
Firmware Access Browser
|
Microsoft Internet Explorer 8.0 or newer (full functionality), Safari with QuickTime installed, and other browsers with VLC installed (partial functionality)
|
|
Compliance
|
ONVIF
|
|
Temperature
|
Starting / Operating: 14 to 113°F (-10 to 45°C)
|
|
Approvals
|
CE (EN 55022 class B, EN 55024), FCC (part15 subpart B class B)
|
|
Dimensions (W x H x D)
|
3.8 x 3.8 x 1.8" (96.5 x 96.5 x 45.7 mm)
|
|
Weight
|
0.45 lb (0.20 kg)
|
