Product Specification |
Overview | Reyee RG-NBR6215-E High-performance Security Router รองรับ Loadbalance 6 WAN, IPSec VPN/ L2TP with IPSecs/ PPTP, รองรับ Internet Throughput 2.5Gbps, รองรับ Users 1500 Concurrent 1 Port SFP และ 1 Port SFP+ รองรับความเร็ว 10Gbps รองรับ Harddisk ขนาด 1TB (Not Include) รองรับการทำ Captive Portal ผ่าน Ruijie Cloud รองรับการ Managed และ Monitor by Ruijie Cloud มาพร้อม Cloud License ตลอดชีพ |
WAN Port | 1 x 10/100/1000 Base-T port |
LAN Port | 1 x 10/100/1000 Base-T port |
LAN/WAN Switchable Port | 6 x 10/100/1000 Base-T ports
1 x 1GBase-X SFP port
1 x 10GBase-X SFP+ port |
Throughput | 2.5 Gbps |
Client (Recommended) | 1500 |
CPU | 4 Cores, 1.2 GHz |
SDRAM/RAM | 2 GB |
Flash Memory | 8 MB |
Hard Disk Drive | 1 TB (Not delivered with the router, can be added) |
LED | 1 x System Status LED
1 x Power Status LED
1 x SATA LED |
Button | 1 x Power button |
Dimensions (W x D x H) | 440 mm x 43.6 mm x 200 mm (17.32 in. x 1.72 in. x 7.87 in., without rubber pads) |
Mounting Method | Rack-mounted |
Rack Size | 1U 19-inch Rack-mounted |
Fan | 2 |
Operating Temperature | 0ºC to 45ºC (32°F to 113°F) |
Operating Humidity | 10% to 90% RH (non-condensing) |
Max Managed Access Points | 64 Access points or 128 wall-mounted access points |
PPPoE Server Accounts | 64 |
Internet Access Mode | PPPoE Client
DHCP Client
Static IP |
Access Mode Auto-Identification | Support |
WAN Address Collision Avoidance | Support |
VLAN | Support |
IPv6 | Support |
SNMP | Support |
Port Isolation | Support |
Port Mirroring | Support |
LAN Port Link Aggregation | Support |
AC Mode | Support |
Application Identification | Support |
Application Priority | Support |
Behavior Management | App Block (Time/IP-based Policy)
Website Filtering
Blacklist/Whitelist |
Flow Control | User Flow Control Policies
IP-based Automatic Bandwidth Assignment
VPN Flow Control |
Local Authentication | Portal Authentication
Password Authentication
Voucher Authentication |
L2TP VPN | Support |
PPTP VPN | Support |
IPsec VPN | Support |
L2TP/PPTP Tunnels | 1000 |
L2TP/IPsec VPN Performance | 1000 Mbps |
Static Routing | Support |
RIP/RIPng | Support |
OSPFv2 | Support |
OSPFv3 | Support |
Equal-Cost Multi-Path Routing | Support |
Policy-Based Routing | Support |
Active/Standby Switchover of Ports | Support |
WAN Load Balancing | Support |
PPPoE Client | Support |
PPPoE Server | Support |
DHCP Server | Support |
DHCP Snooping | Support |
DNS Client | Support |
DNS Server | Support |
DNS Proxy | Support |
FTP Client | Support |
FTP Server | Support |
TFTP Client | Support |
NTP Client | Support |
DDNS | Cloud DNS |
NAT | Support |
SNMP | Support |
Ruijie Cloud | Support |
ACL | Support |
Time-based Extended ACL | Support |
SYN Flood Attack Guard | Support |
UDP Flood Attack Guard | Support |
ICMP Flood Attack Guard | Support |
ICMP Redirection Attack Guard | Support |
ICMP Unreachable Packet Attack Guard | Support |
Fraggle Attack Guard | Support |
Overlength ICMP Packet Attack Prevention | Support |
Winnuke Attack Guard | Support |
IP-based Security Domain Division | Support |
Security Domain Division based on Physical Port (Sub Interface and Aggregation Port) and Dialup Port | Support |
Cloud Management | Support |
App Management | Support |
App Upgrade | Support |
App Restart | Support |
ประกัน | 3 ปี |
