RG-ES220GS-P
Reyee Cloud Managed Smart Switch 20 Port Gigabit, 2 Port SFP, จ่ายไฟ POE 16 Port มาตรฐาน 802.3af/at กำลังไฟสูงสุด 250W บริหารจัดการผ่าน Ruijie Cloud
ตัวแทนจำหน่าย Ruijie อย่างเป็นทางการ สอบถามราคาส่วนลดพิเศษ
Support / ติดตั้งด้วยทีมงาน Certificate
สอบถามรายละเอียดสินค้าเพิ่มเติม LINE: @sysnet
Click ต้องการใบเสนอราคา
Review Ruijie RG-ES200 Series Cloud Managed POE Switch สำหรับงาน CCTV, WIFI
Review Ruijie Reyee POE Switch รองรับ Managed ผ่าน Ruijie Cloud
Review Ruijie Cloud ระบบ Managed & Monitor อุปกรณ์ Ruijie ผ่าน Cloud ฟรี
Reyee Series Implementation Cookbook V1.0
RG-ES200 Series Web-Based Configuration Guide
Ruijie RG-ES200 Series Switches Hardware Installation and Reference Guide
RG-ES205GC Quick Installation Guide
RG-ES200 Series Datasheet
L2-Managed Gigabit POE Switch 20 Port ความเร็ว Gigabit มาพร้อม Port SFP สำหรับใส่ SFP Module x 2 เพื่อเชื่อมต่อผ่านสาย Fiber Optic 2 Port ให้ได้ระยะที่ไกลกว่าสาย UTP
สามารถจ่ายไฟ POE มาตรฐาน 802.3af/at (15.4W/30W) ได้ 16 Port รวมกำลังไฟสูงสุด 250W เฉลี่ยต่อ Port 15W
*** กรณีกล้องพวก Speed Dome หรือ Access Point ประเภท 3x3, 4x4 ที่ใช้กำลังไฟสูงๆ (เกิน 13.5W) เชื่อมต่อหลายๆอุปกรณ์ แนะนำให้คำนวนให้ดีครับ หรือ ส่ง Spec อุปกรณ์ให้ทางร้านคำนวนให้ได้เลย
หรือ
กรณีใช้กับ Access Point ที่เป็น WIFI 6 ถ้าติดตั้งหลายๆตัว ค่า Forwarding Rate อาจจะไม่พอ แนะนำเป็น Reyee Series NBS3100 ขึ้นไปจะดีกว่าครับ
รุ่นนี้ Port Uplink จะเป็น SFP Port ครับ ส่วน Port LAN RJ45 จ่ายไฟ POE 16 Port อีก 2 Port สามารถต่อ Uplink เข้ากับ Router หรือ Core Switch กรณีใช้กับระบบ CCTV สามารถต่อเข้ากับ NVR ได้เลย
POE Switch RG-ES220GS-P Product Specification |
|
Ports |
RG-ES220GS-P 16 Ports 10/100/1000 Base-T จ่ายไฟมาตรฐาน IEEE 802.3af/at (PoE/PoE+) |
Maximum output power per PoE port |
30W |
10/100/1000Base-T ports |
18 |
1000Base-X SFP ports |
2 |
PoE/PoE+ ports |
16 |
Max. PoE budget |
250W |
Layer Type |
Layer 2 |
Switching capacity |
40 Gbps |
Forwarding rate |
29.76 Mpps |
Packet Buffer |
4.1 Mbit |
MAC address table |
8000 |
Maximum VLAN Support |
16 |
Dimensions (W x D x H) |
300 mm x 223 mm x 43.6 mm |
Weight (With package) |
2.8 kg |
MTBF (Hours) |
> 200,000 |
Software Features |
|
10/100/1000M Auto/Full/Half Duplex Negotiation |
Support |
Flow Control |
Support |
Storm Suppression |
Support |
Management IP |
10.44.77.200 |
VLAN |
Support 802.1Q VLAN |
Port-based VLAN |
Support |
DHCP Client |
Support |
DHCP Snooping |
Support |
Many-to-one Port Mirroring |
Support |
Downlink Loop Protection |
Support |
Loop Disabled Port |
Support |
Disconnection Duration |
Support |
Cable Testing |
Support |
Management |
Web-based Management |
Reset Button |
Front |
Power Supply Slot |
Single, fixed power supply |
Power Consumption |
≤ 280W |
Power Supplies |
100 - 240V AC, 6A |
Fan Adaptive Speed Adjustment |
Support |
Acoustic Noise |
< 45dB |
Operating Temperature |
0°C to 40°C |
Storage Temperature |
-40°C to 70°C |
Operating Humidity |
10% to 90% RH |
Storage Humidity |
5% to 95% RH |
Port Surge |
4 kV |
Certificate |
CE, RoHS |
ประกัน |
ทางร้านเป็นตัวแทนจำหน่ายอย่างเป็นทางการ ประกันศูนย์ Ruijie Thailand 3 ปี |
Gigabit access PoE switch fits needs in SMB network
ES200 adopts a light-weighted Cloud management design, providing faster response to support richer features.
Network stays connected when network loop happens.
