Dimensions

270*94.86*67.5mm

Frequency Range

5GHz

Maximum wireless speed

300Mbps

GND Terminal

1

Interface

1* 10/100 LAN port

Mode Switch

Station: The device only work in Station mode
Off: The device work on AP/Station/Universal Repeater/WISP/Router mode
AP: The device only work in AP mode

Button

Reset: Press 10 seconds or more to restore to default settings
Bridge: Press 3 seconds and release it to bridge uplink AP

Antennas

14dbi Directional Antenna

Antenna Beamwidth

Horizontal: 30°
Vertical: 30°

Maximum Power Consumption

8.5W

Lightning Protection

6KV

Waterproof Level

IP64

LED indicator

LAN,LED1,LED2,LED3

Power Supply

24v 0.5A PoE Injector

Operating mode

AP/Station/Universal Repeater/WISP/Router

Compliant Standards

IEEE 802.11/n/a

Wireless Features

Enable/Disable Wireless Radio
SSID Hidden
Wireless Client isolation
Sensitivity Threshold
WMM Capable
APSD Capable
Wireless Access Control
Wireless Client list

Wireless Security

64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2

Transmission Power

Adjustable power by 1dBm

Receiver sensitivity

MCS0: -96dbm
MCS7: -72dbm

DHCP Server

DHCP Server
Clients list

VPN Pass-Through

PPTP,L2TP

Remote Web access

Support

Schedule Reboot

Support

Page Timeout

Support

Ping Watchdog

Support

Speed Test

Support

Dyndns

noip, dyndns.org

Network Diagnoses

Ping, Traceroute, Signal Scan

Management Tool

Time&Date Setting
System Log
Firmware update
Backup/Restore Configuration
Username Managerment

Temperature

Humidity

Default login IP

192.168.2.1

Default Login Username

admin

Default Login Password

admin

Certifications

FCC/CE/RoHS

รับประกัน

สินค้ารับประกัน 5 ปี
