Product Spec | ACTi Z31 Mini Bullet IP-Camera Fixed Lens แบบติดตั้งภายนอกอาคาร ความละเอียด 4MP Mode Day/Night Adaptive IR Extreme WDR, Superior Low Light Sensitivity รองรับ POE 802.3af |
Product Type | Mini Dome |
Maximum Resolution | 4MP |
Application Environment | Outdoor |
Image Sensor | Progressive Scan CMOS |
Sensor Size | 1/3 " |
Effective Pixels | 2688(H) X 1520(V) (4.09 MP) |
Day / Night | Yes |
Low Light Sensitivity | Superior |
Minimum Illumination | Color: 0.02 lux; B/W: 0 lux (IR LED on) |
Mechanical IR Cut Filter | Yes |
IR LED | Adaptive IR LED |
IR Working Distance | 30m |
Electronic Shutter | 1/6-1/100000sec (manual mode); 1/6-1/100000sec (auto mode) |
S/N Ratio | 55 dB |
Lens |
|
Focal Length | Fixed focal, f2.8mm |
Aperture | F2.0 |
Iris | Fixed iris |
Focus | Fixed focus |
Lens Mount | Board mount |
Horizontal Viewing Angle | 101.8? |
Viewing Angle Adjustment | Pan: ?175?, Tilt: 0?-90?, Rotation: ?175? |
Video |
|
Compression | H.265, H.264, MJPEG |
Maximum Frame Rate vs. Resolution | 20 fps at 2592 x 1520 |
Multi-Streaming | Simultaneous triple streams based on three configurations |
Wide Dynamic Range | Extreme WDR (120 dB) |
Image Enhancement | Digital Image Stabilizer, Defogging |
Digital Noise Reduction | 3D DNR |
Privacy Mask | 8 configurable regions |
Built-in Analytics | Object Based Motion Detection, Tamper |
Image Orientation | Flip, Mirror, Rotation |
Audio |
|
Audio Type | 2-way, Mic-in, Line-in, Line-out |
Audio Compression | G.711 |
Network |
|
Ethernet Port | 1 x RJ-45 connector |
Event |
|
Event Trigger | Video motion detection, External device through digital input, Sound detection, Tampering detection |
Event Response | E-mail notification with snapshots, Save video to local storage, Upload snapshot to FTP server, Activate external device through digital output |
Integration |
|
ONVIF Compliant | Yes |
Interface |
|
Audio Interface | RCA Jack |
Local Storage | MicroSDHC, MicroSDXC memory card slot (card not included) |
Digital Input/Output | 1/1 |
General |
|
Power Source | DC 12V, PoE Class 3 (IEEE802.3af) |
Power Consumption | 5.5 W (PoE) |
Weight | 450g (0.99lb) |
Dimensions | (? x H): 108.5mm x 81mm (4.28" x 3.2") |
Environmental Casing | Weatherproof (IP66), Vandal proof (IK10) |
Bundled Accessories | Flush mount |
Mount Type | Flush |
Operating Temperature | -35?C ~ 60?C (-31?F ~ 140?F) |
Approvals | CE, FCC, IP66, IK10 |
Warranty | 3 Year(s) |
