Product Specification | |
Overview | อุปกรณ์ Router Board พร้อม Case และ Power Supply ของ Mikrotik รุ่น RB493G-Set รองรับระบบ L7 Firewall, การจำกัดความเร็ว Internet แต่ละ Client (Bandwidth Management), Block Bittorrent, Dynamic Routing Protocol (RIP, OSPF, BGP), Secure Tunnel (EoIP, PPPoE, PPTP, L2TP, OVPN 200 Connection), VLAN, P2P Firewall Rules, Nat Rules, รองรับ Hotspot Gateway (Create 500 User), Radius Client, Unlimited Queues, User Manager (50 Users สามารถ Login ใช้งานพร้อมกัน), Synchronous Interface, รองรับการทำ Radius Server และ Radius Client |
CPU | Atheros AR7161 680MHz |
Operating System | MikroTik RouterOS v4, Level5 License |
Hotspot Account | รองรับได้ 500 Account, Login ได้พร้อมกัน 50 Account |
Memory | 256 MB DDR SDRAM onboard memory |
Data storage | 128 MB onboard NAND storage chip |
Ethernet | Port RJ-45 จำนวน 9 Port ความเร็วระดับ Gigabit 10/100/1000 Mbps. สามารถ Config แต่ละ Port แยกอิสระจากกันได้ |
miniPCI | 3 miniPCI Slots |
Serial port | 1 Port RS232 (Serial Console) |
USB | 1 Port USB รองรับ 3G Modem |
LEDs | Power, NAND activity, 5 Ethernet LEDs |
Power options | 8V - 28V DC - power jack, 18V -28VDC passive PoE (Ethernet port 1) |
Dimensions | - |
Weight | - |
Operating Temperature | -20C ถึง +50C |
กำลังไฟ | ประมาณ 6W (Server ใช้ประมาณ 400-500W) |
รับประกัน | 1 ปี, Adaptor 3 เดือน |
Support | สอบถาม Solution ที่ต้องการก่อนสั่งซื้อครับและไม่รับ Support ในส่วน การทำ Loadbalance? |
เนื่องจากอุปกรณ์ Mikrotik สามารถที่จะ Config ได้หลากหลายรูปแบบ ในบางปัญหา ทางร้านจะไม่สามารถหาวิธีแก้ไขให้ได้ รวมถึง RouterOS ที่มีการ Update อยู่บ่อยครั้ง ทางร้านขอสงวนสิทธิ์ในการบริการหลังการขายและ Support ตามนี้ครับ
อุปกรณ์ Mikrotik Router (CRS1xx, CRS2xx, RB9xx, hEX, RB4xx, RB2011, RB7xx, hAPxxx, CCRxxx, RB3xxx, RB600, RB8xxx, RB11xx, RB12xx, CRS3xxxx, RB3011)
Config ระบบ Hotspot Authenticate , ค่าเบื้องต้นในการเชื่อมต่อ Internet , Hotspot Server, NAT Firewall, IP Address, DHCP Client/Server, Bridge Interface, PPPoE Client, User-Manager, Radius, NTP, Backup Config
ในกรณีที่ทำระบบ Hotspot และ ทางลูกค้าต้องการติดตั้ง SSL Certificate ทางร้านจะมีไฟล์ SSL ส่งให้ และทางลูกค้าทำการติดตั้งเอง ตามในหัวข้อนี้ครับ วิธีติดตั้ง SSL Certificate บน Mikrotik โดยจะมีอายุ 1 ปี (ปกติทางร้านจะต่อทุกปีครับ แต่พอครบปี ไฟล์เดิมจะใช้ไม่ได้ ลูกค้าต้องทำการ Import File เข้าไปใหม่)
กรณีที่ลูกค้าต้องการใช้ Mikrotik สำหรับทำ Loadbalance แล้วทำระบบ Hotspot ,ทำ VLAN แยก SSID แต่ละชื่อ WIFI , Forward Port เพื่อเชื่อมต่อจากภายนอกมายังอุปกรณ์ภายในระบบ Network ทางร้านขออนุญาติคิดค่าใช้จ่ายเพิ่มเติมตามด้านล่างนี้ครับ
